| Westerschelde 05 September 2020 |
 |
| Westerschelde 05/09/20 |
|
Name |
HAFNIA TORRES |
|
Type |
Oil product tanker |
|
IMO-number |
9729283 |
|
Call sign |
9V3283 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
24.120 t Suez: 25.484,72 t |
|
DWT |
Summer: 39.067 t Winter: 37.936 t |
|
NT |
10.359 t Suez: 21.671,99 t Panama: 20.166 t |
|
Displacement |
Summer: 48.445 t Winter: 47.314 t |
|
Length |
184,26 m overall 176,00 m between perpendiculars |
|
Breadth |
27,44 m extreme |
|
Draught |
Summer: 11,92 m Winter: 11,67 m |
|
Keel to mast end |
46,40 m |
|
Air draft |
Summer deadweight: 34,68 m Normal ballast: 39,24 m Lightship: 44,15 m |
|
Freeboard |
Summer: 5.713 mm Winter: 5.961 mm |
|
Depth |
17,60 m moulded |
|
Speed |
Ballast: Max: 16,9 knots / Economic: 13,4 knots Laden: Max: 16,2 knots / Economic: 12,8 knots |
|
Built |
2016 |
|
Keel laid |
24/12/2015 |
|
Launch date |
07/03/2016 |
|
Date of completion |
04/05/2016 |
|
Builder |
Hyundai Mipo Dockyard Ulsan South Korea |
|
Yard number |
2574 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Hyundai 6S50ME-B9.3 TIER:II - 2 stroke 6 cylinder 500 x 2.214 mm combustion engine 7.290 kW / 9.911 hp at 99,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Generators |
3x Hyundai/Himsen 6H21/32 main diesel generatorsets each 1.070 kW at 900 rpm |
|
Number of tanks |
12 |
|
Cargo tank capacity 98% |
CC1P = 2.572,892 m³ CC1S = 2.563,876 m³ CC2P = 3.648,736 m³ CC2S = 3.645,600 m³ CC3P = 3.712,142 m³ CC3S = 3.717,532 m³ CC4P = 3.712,142 m³ CC4S = 3.717,532 m³ CC5P = 3.712,142 m³ CC5S = 3.717,532 m³ CC6P = 3.452,638 m³ CC6S = 3.457,146 m³ Total: 41.629,91 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
Stbd slop 334,93 m³ Port slop 536,07 m³ |
|
Number of pumps |
10x Centrifugal cargo pumps each 500 m³/h 2x Centrifugal cargo pumps each 300 m³/h 2x Centrifugal cargo pumps each 200 m³/h 2x Submerged ballast pumps each 750 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 57,63 m Bow to centre manifold: 92,58 m Stern to centre manifold: 91,68 m Distance between cargo manifold centres: 2.000 mm Distance ships rail to manifold: 4.500 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 700 mm Distance main deck to centre of manifold: 2.100 mm Spill tank grating to centre of manifold: 900 mm |
|
Tank capacities |
Fuel oil: 1.176,4 m³ Diesel oil: 450,1 m³ |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Crew |
21 |
|
Commercial manager |
Hafnia Pools Pte. Ltd. as agents to owners Mapletree Business City, #18-01 10 Pasir Panjang Road Singapore 117438 Republic of Singapore |
|
ISM manager |
Thome Croatia Doo ulica 7 Domobranske Pukovnije 1 HR-23000 Zadar Croatia |
|
Owner |
Hafnia Tankers Shipholding Singapore Pte Ltd. 18-01, Mapletree Business City 10, Pasir Panjang Road Singapore 117438 Republic of Singapore |
|
Latest data adjustment |
06 December 2021 |
