Westerschelde 10 June 2020 |
 |
 |
|
| Westerschelde 07/11/19 | Westerschelde 07/11/19 | |
|
Name |
GISELA ESSBERGER |
|
Previous names |
1998 - 11/2005 Giovanni Fagioli 11/2005 - 06/2008 Euro Skye 06/2008 - 05/2018 Crystal Skye |
|
Type |
Chemical / Oil products tanker |
|
IMO-number |
9147734 |
|
Call sign |
CQAE5 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flags |
1998 - 2010 United Kingdom - Call sing: MJVC7 2010 - 2018 Malta, Valletta - Call sign: 9HA2161 |
|
GT |
6.572 t Suez: 6773,71 t Panama: 5.577 t |
|
DWT |
Summer: 9.554 |
|
NT |
3.000 t |
|
Displacement |
Summer: 13.531 t |
|
Length |
125,20 m overall 115,70 m between perpendiculars |
|
Breadth |
19,64 m extreme |
|
Draught |
Summer: 7,60 m |
|
Keel to top of the mast |
37,00 m |
|
Depth |
9,55 m |
|
Speed |
14,5 knots |
|
Built |
1998 |
|
Keel laid |
24/01/1997 |
|
Delivery date |
16/04/1998 |
|
Builder |
Cantieri Navali Fratelli Orlando S C.A.R.L. Livorno Italy |
|
Yard number |
162 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Stork-Wärtsilä 8L38 - 4 stroke 8 cylinder 380 x 475 mm combustion engine 5.280 kW / 7.178 bhp at 600 rpm Builder: Wärtsilä NSD Nederland B.V., Zwolle - The Netherlands |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
Thermal oil and economizer |
|
Shaft generator |
1x 1.200 kW |
|
Generators |
3x Main diesel generatorsets each 777 kW |
|
Emergency generator |
1x Diesel generatorset 350 kW |
|
Bow thruster |
1x Brunvoll 750 bhp / 552 kW |
|
Number of cargo tanks |
22 + 2 slop tanks |
|
Cargo tank capacity 98% |
10.439,73 m³ |
|
Cargo pumps |
22x Deepwell each 200 m³/h 2x Deepwel each 100 m³/h |
|
Max loading/discharging rate |
1.200 m³/h |
|
Heating capacity |
60°C |
|
Manifold |
Centre manifold to deck: 3.000 mm Centre manifold to stern: 67,60 m Centre manifold to bow: 57,60 m Centre manifold to rail: 2.954 mm |
|
Tank capacities |
Fuel oil: 479,5 m³ Diesel oil: 105,5 m³ |
|
Lifting equipment |
2x Hose crane - SWL 5,0 t each 1x Hose crane - SWL 2,0 t |
|
Crew size |
25 |
|
ISM & commercial manager |
John T. Essberger GmbH & Co. KG Palmaille 45 22767 Hamburg Germany |
|
Registered owner |
KG 45 Oceania Schiffahrtsgedellschaft mbH & Co. Palmaille 45 22767 Hamburg Germany |
|
Latest data adjustment |
27 September 2023 |
