Name |
CHEM NEW YORK |
|
Type |
Chemical and oil product tanker |
|
IMO-number |
9705732 |
|
Call sign |
D5FT9 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
12.129 t registered |
|
DWT |
19.994,13 t |
|
NT |
6.255 t registered |
|
Length |
145,00 m overall |
|
Breadth |
24,20 m moulded |
|
Draught |
Summer: 9,78 m |
|
Moulded L x B x D |
139,00 x 24,20 x 13,20 m |
|
Registered L x B x D |
139,26 x 24,20 x 13,20 m |
|
Keel to mast end |
37,15 m |
|
Freeboard |
Summer: 3.445 mm |
|
Depth |
13,20 m moulded |
|
Speed |
Max: 16,1 knots Service: 14,5 knots |
|
Built |
2014 |
|
Keel laid |
07/02/2014 |
|
Launch date |
17/07/2014 |
|
Date of completion |
17/10/2014 |
|
Builder |
Kitanihon Shipbuilding Co. Ltd. Hachinohe Japan |
|
Yard number |
567 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi-Akasaka 6UEC43LSII - 2 stroke single acting 6 cylinder 430 x 1.500 mm combustion engine 4.800 kW at 125,0 rpm Manufacturer: Akasaka Diesels Ltd., Shizuoka - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 390 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 9,0 bar Evaporation: 16,28 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 530 kW |
|
Bow thruster |
700 kW |
|
Number of cargo tanks |
20 |
|
Cargo tank capacity |
Liquid: 22.392 m³ |
|
Number of pumps |
20x Cargo pumps each 250 m³/h |
|
Tank capacities |
Fuel oil: 1.107 m³ Fresh water: 415 m³ |
|
Crew |
19 |
|
Commerical manager |
Ace Quantum Chemical Tankers CV Strawinskylaan 1997 1077 XX Amsterdam The Netherlands |
|
ISM manager |
Fleet Management Ltd. 27th Floor, South Island Place 8, Wong Chuk Hang Road, Southern, Hong Kong China |
|
Registered owner |
Chem New York SA, Monrovia - Liberia Care of Ace Quantum Chemical Tankers CV Strawinskylaan 1057 1077 XX Amsterdam The Netherlands |
|
Latest data adjustment |
05 July 2022 |
