Bow Sagami - IMO 9379911

Westerschelde 07 June 2015

Name

BOW SAGAMI

Type

Oil/Chemical carrier

IMO-number

9379911

Call sign

3ERTH

Flag

Republic of Panama

Port of registry

Panama City

GT

19.420 t registered

Suez: 20.478 t

DWT

Summer: 33.614 t

NT

9.793 t registered

Light ship

7.959 t

Suez: 18.567 t

Panama: 16.220 t

Length

170,00 m overall

Breadth

26,63 m extreme

Draught

Summer: 11,32 m

Moulded L x B x D

162,00 x 26,60 x 16,00 m

Registered L x B x D

162,83 x 26,60 x 16,00 m

Keel to top of mast

39,00 m

Freeboard

Summer: 4.717 mm

Depth

16,00 m moulded

Speed

Service: 13,6 knots

Max: 16,5 knots

Built

2008

Keel laid

18/03/2008

Launch date

23/07/2008

Date of completion

10/10/2008

Builder

Kitanihon Shipbuilding Co., Ltd.

Hachinohe

Japan

Yard number

380

Hull material

Steel

Hull type

Double hull

Main engine

1x Akasaka-Mitsubishi - 2 stroke single acting 6 cylinder 520 x 1.850 mm combustion engine 7.980 kW at 120 rpm

Manufacturer: Akasaka Diesels Ltd., Shizuoka - Japan

Propeller shaft

1x Oil lubrication shaft without monitoring device

Diameter: 460 mm

Propellers

1x Fixed propeller

Boilers

2x Auxiliary vertical boiler - 9,0 bar

Evaporation: 11,24 t/h

Manufacturer: Miura Co., Ltd.

Generators

4x Generatorsets total 2.289 kVA

Bow thruster

950 kW

Number of cargo tanks

16

Cargo tank capacity 100%

Liquid: 37.998 m³

Manifolds

Summer Waterline to Manifold: 7,86 m

Normal ballast waterline to manifold: 11,94 m

Rail to manifold: 4,33 m

Bow to centre of manifold: 82,80 m

Tank capacities

Fuel oil: 1.837 m³

Fresh water: 456 m³

Ballast: 13.157 m³

Manager

Odfjell Asia Pte Ltd.

6 Shenton Way # 27-08/09

OUE Downtown 2

Singapore

Republic of Singapore

Owner

Chemtrans Navigation S.A.

Renamed

2018 Sagami

Republic of Panama, Panama City - Call sign: 3ETH

Reg. Owner: Chemtrans Navigation S.A.

Manager: Fleet Management Limited

Latest data adjustment

15 May 2020
