Federal Maas 03

Antwerpen 26 May 2016



Federal Maas 04   Federal Maas 01   Federal Maas 02
26/05/16   13/01/16   13/01/16



Name

FEDERAL MAAS

Type

Bulk carrier

IMO-number

9118135

Call sign

8POB

Flag

Barbados

Port of registry

Bridgetown

GT

20.837 t registered

DWT

Summer: 34.167 t

Winter: 33.223 t

Tropical: 35.113 t

NT

11.404 t registered

Panama: 17.387 t

Suez: 18.080 t

Length

200,00 m overall

191,00 m between perpendiculars

Breadth

23,55 m extreme

23,49 m moulded

Draught

10,74 m

Depth

14,89 m

Speed

14,0 knots

Built

1997

Keel laid

05.08.1996

Launch date

29.10.1996

Date of completion

27.03.1997

Builder

Jiangnan Shipbuilding (Group) Co.
Shanghai
China

Yard number

2218

Hull material

Steel

Hull type

Single hull

Bulkheads

Transverse: 8

Main engine

1x MAN B&W 6S50MC - 2x Stroke 6 cylinder diesel engine

Propellers

1x Fixed pitch propeller

Boilers

1x Auxiliary boiler, composite type GCS-22

Generators

3x Daihatsu 6DKB-20 diesel generatorsets

Emergency generator

1x MAN D0226 MLE diesel generatorset

Number of holds

6

Hold 1: 23,00 x 7,50/17,80 m

Hold 2: 24,00 x 18,00 m

Hold 3: 26,80 x 18,00 m

Hold 4: 24,00 x 18,00 m

Hold 5: 26,80 x 18,00 m

Hold 6: 23,00 x 17,80/11,50 m

Cargo hold capacity

Grain / bale

Hold 1: 6.180 / 5.951 m³

Hold 2: 6.950 / 6.641 m³

Hold 3: 7.795 / 7.519 m³

Hold 4: 6.868 / 6.606 m³

Hold 5: 7.804 / 7.527 m³

Hold 6: 6.266 / 6.093 m3

Total: 41.863 / 40.337 m³

Number of hatches

6

Hatch 1: 14,40 x 13,10 m

Hatch 2: 18,40 x 13,10 m

Hatch 3: 20,00 x 13,10 m

Hatch 4: 18,40 x 13,10 m

Hatch 5: 20,00 x 13,10 m

Hatch 6: 16,00 x 13,10 m

Hatch cover type

Folding hydraulic

Tank capacities

Ballast: 18.615,93 m³

Intermediate fuel oil: 1.373 m³

Marine diesel oil: 432 m³



Cargo gear

3x Electro hydraulic cranes - SWL 30, t each

3x Grabs each 10,0 m³

Manager

Anglo-Eastern Ship Management Limited
Hong Kong
China

Operator

Fednav Ltd.

Owner

Fednav Group
Montreal
Canada

Registered owner

Federal Atlantic Ltd.

Previous owners

1997 - 2007 Great Lakes Inc.

Latest data adjustment

27 April 2016
