Westerschelde 06 August 2015 |
|
Name |
FEDERAL MATTAWA |
|
Type |
Bunker carrier |
|
IMO-number |
9315537 |
|
Call sign |
9HA3162 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
18.825 t |
|
DWT |
Summer: 27.428 t Winter: 26.620,6 t |
|
NT |
8.565 t Panama: 15.727 t Suez: 15.745 t |
|
Length |
185,07 m overall 177,04 m registered |
|
Breadth |
23,50 m registered |
|
Draught |
9,80 m |
|
Forecastle |
12,84 m |
|
Poop |
23,73 m |
|
Depth |
14,10 m moulded |
|
Speed |
14,0 knots |
|
Built |
2005 |
|
Keel laid |
15.11.2004 |
|
Launch date |
05.06.2005 |
|
Date of completion |
11.08.2005 |
|
Builder |
Guangzhou Wenchong Shipyard Co., Ltd. |
|
Yard number |
GWS308 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x B&W-Hudong 6S46MC-C - 2 stroke 6 cylinder 460 x 1.932 mm diesel engine - 7.860 kW at 129,0 rpm Year of manufacture: 2005 Manufacturer: Hudong Heavy Machinery Co., Ltd. |
|
Propellers |
1x Solid propeller (keyless) - aft at 129,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 34,0 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 200,0 m² Year of manufacture: 2005 Manufacturer: Zhangjiagang Greens Shazhou Boiler Co., Ltd. |
|
Electric installations |
3x Plants each 450/220 V - 750 kVA 1x Plant 450 V - 131 kVA 1x Plant 24 V - 73 Ah 1x Plant 24 V - 200 Ah 4x Plants each 24 V - 200 Ah |
|
Generators |
3x Main diesel generatorsets each 750 kVA |
|
Emergency generator |
1x Diesel generatorset 131 kVA |
|
Batteries |
1x Battery for automation200 Ah |
|
Compressed air receivers |
1x Receiver 30 litres - 33,0 bar 2x Receivers each 4.500 litres - 30,0 bar 1x Receiver 160 litres - 30,0 bar 1x Receiver 250 litres - 10,0 bar 1x Receiver 100 litres - 9,0 bar |
|
Bow thruster |
1x Transverse thruster 680 kW, forward |
|
Number of holds |
5 Hold 1: 24,8 x 8,80 / 13,00 m Hold 2: 27,20 x 19,00 / 19,00 m Hold 3: 28,80 x 19,00 / 19,00 m Hold 4: 27,20 x 19,00 / 19,00 m Hold 5: 28,80 x 19,00 / 13,00 m |
|
Hold capacity |
Grain / Bale: Hold 1: 4.898 m³ / 4.720 m³ Hold 2: 7.203 m³ / 7.050 m³ Hold 3: 7.628 m³ / 7.030 m³ Hold 4: 7.190 m³ / 7.030 m³ Hold 5: 7.456 m³ / 6.900 m³ Total: 34.375 m³ / 32.730 m³ |
|
Number of hatches |
5 Hatch 1: 15,20 x 15,20 m Hatch 2: 20,80 x 19,00 m Hatch 3: 20,80 x 19,00 m Hatch 4: 20,80 x 19,00 m Hatch 5: 20,80 x 19,00 m |
|
Hatch type |
Folding hydraulic |
|
Max.: permitted loads |
Tanktop: 20,0 t/m² |
|
Tank capacities |
IFO: 945 m³ MDO: 436 m³ |
|
Anchor equipment |
3x Anchors weight each 6.450 kg Chain length: 605,00 m |
|
Cargo gear |
3x Electro hydraulic cranes - SWL 30,0 each |
|
Crew size |
23 |
|
Manager |
Norddeutsche Reederei H. Schuldt GmbH & Co. KG |
|
Operator |
Fednav Group |
|
Registered owner |
Ocean Castle Shipping Ltd. |
|
Latest data adjustment |
30 August 2015 |
