Westerschelde 25 August 2016 |
 |
 |
 |
 |
|||
| Westerschelde 24/08/16 | Westerschelde 24/09/18 | Westerschelde 16/06/12 | Westerschelde 10/04/17 | |||
|
Name |
IMKE |
|
Type |
Multi-purpose dry cargo carrier - heavycargo - Containership |
|
IMO-number |
9341756 |
|
Call sign |
PHGG |
|
Flag |
The Netherlands |
|
Port of registry |
Westerbork |
|
GT |
3.999 t |
|
DWT |
6.000 t |
|
NT |
2.208 t |
|
Number of 20ft containers |
242 |
|
Length |
110,78 m overall 105,48 m between perpendiculars |
|
Breadth |
14,00 m moulded |
|
Draught |
Max.: 6,09 m |
|
Air draft |
27,25 m |
|
Freeboard |
2.054 mm |
|
Depth |
8,13 m moulded |
|
Speed |
14,0 knots |
|
Built |
2006 |
|
Keel laid |
14/02/2006 |
|
Launch date |
23/06/2006 |
|
Date of completion |
19/07/2006 |
|
Builder |
Ferus Smit Scheepswerf BV Hoogezand The Netherlands |
|
Yard number |
366 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke single acting 8 cylinder 255 x 400 mm diesel engine 2.640 kW / 3.587 hp at 750 rpm Built: 2006 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 200 rpm |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Shaft generator |
1x 488 kVA - 390 kW |
|
Generators |
2x Main diesel generatorsets each 175 kVA - 140 kW - 222 hp |
|
Emergency generator |
1x Diesel generatorset 52 kVA - 42 kW - 68 hp |
|
Number of holds |
2 Hold 1: 27,58 x 11,47 x 9,00 m Hold 2: 50,88 x 11,47 x 9,00 m |
|
Hold capacity |
Grain: 7.928 m³ |
|
Cargo hatchways |
2 Hatch 1: 27,58 x 11,47 m Hatch 2: 50,88 x 11,47 m |
|
Fuel capacity |
370 m³ |
|
Manager |
Wagenborg Shipping Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Owner |
Hanno H. van Dijk Westerbork The Netherlands |
|
Registered owner |
C.V. Scheepvaartonderneming Imke Westerbork The Netherlands |
|
Renamed |
16/10/2022 Neuseborg The Netherlands, Delfzijl - Call sign: PGHH Owner: Wagenborg Shipowners 5 B.V., Delfzijl - The Netherlands Manager: Wagenborg Shipping B.V., Delfzijl - The Netherlands |
|
Latest data adjustment |
09 November 2023 |
