Westerschelde 25 April 2017 |
 |
 |
|
| Westerschelde 28/02/20 | Westerschelde 15/04/14 | |
|
Name |
IMI |
|
Previous names |
1993 - 08/2006 Marja |
|
Type |
General cargo ship - -Container ship - Carriage of dangerous goods |
|
IMO-number |
9063873 |
|
Call sign |
C6VT4 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
Previous flags |
1993 - 2006 The Netherlands, Rotterdam - Call sign: PFUG |
|
GT |
2.715 t |
|
DWT |
Summer: 4.297 t |
|
NT |
1.586 t |
|
Displacement |
5.447 t |
|
Number of 20ft containers |
In hold: 117 On deck: 80 Total: 197 |
|
Length |
89,90 m overall 84,99 m between perpendiculars |
|
Breadth |
13,17 m moulded |
|
Draught |
Summer: 5,61 m |
|
Air draft |
18,60 m minimum |
|
Depth |
7,15 m moulded |
|
Speed |
12,5 knots Service: 11,0 knots |
|
Built |
1993 |
|
Launch date |
16/07/1993 |
|
Date of completion |
14/10/1993 |
|
Builder |
Scheepswerft Bijlholt B.V. Foxhol The Netherlands |
|
Yard number |
689 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Movable bulkheads |
2x Portable bulkhead may be placed in 6 positions for cargo |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8V25 - 4 stroke single acting 8 cylinder 250 x 300 mm combustion engine 1.690 kW / 2.290 hp at 825 rpm Built: 1993 Buider: Wärtsilä Diesel Trollhattan - Finland |
|
Gearbox |
1x Valmet Miva 710+S315 - reduction: 4.39:1 |
|
Propellers |
1x Berg 800 HX screw propeller controllable pitch aft at 188 rpm Diameter: 2.800 mm - 4 blades |
|
Electric installations |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Shaft generator |
1x 270 kVA - 216 kW |
|
Generators |
2x Valmet 620 DSG - 6 cylinder 108 x 120 mm diesel engine each 90 kW at 1.500 rpm coupled with Stamford UCM274 E23 generators each 112 kVA |
|
Emergency generator |
1x Valmet 420-DG - 4 cylinder 108 x 120 mm diesel 41 kW at 1.500 rpm Stamford UCM-434E generator 63 kVA |
|
Bow thruster |
1x 260 kW |
|
Number of holds |
1 62,52 x 11,00 x 8,38 m |
|
Hold capacity |
Grain & Bale: 203.540 ft³ / 5.764 m³ |
|
Number hatches |
1 62,52 x 11,00 m |
|
Hatch type |
Coops en Nieborg pontoon system |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Hatch cover: 1,6 t/m² |
|
Tank capacities |
Ballast 1.600 m³ Fuel 236,0 m³ Fresh water 52,0 m³ Lub oil 6,0 m³ Sewage: 12,52 m³ Sludge: 8,71 m³ |
|
Lifting equipment |
1x Gantry crane - SWL 6,0 t |
|
Manager |
Misje rederi AS C. Sundts gate 39 5004 Bergen Norway |
|
Previous managers |
10/1993 - 12/2004 Heinrich Hanno & Co B.V., Rotterdam - The Netherlands 12/2004 - 08/2006 Arklow Shipping Nederland B.V., Rotterdam - The Netherlands |
|
Owner |
Misje Bulk A/S |
|
Previous names & owners |
10/1993 - 12/2004 Marja - Rederij Marja B.V., Rotterdam - The Netherlands 12/2004 - 08/2006 Marja - Arklow Shipping Nederland B.V., Rotterdam - The Netherlands |
|
Latest data adjustment |
26 February 2023 |
