Westerschelde 20 September 2018 |
 |
 |
 |
 |
 |
||||
| Vlissingen 30/11/16 | Antwerpen 16/04/13 | Antwerpen 16/04/13 | Westerschelde 27/11/13 | Westerschelde 08/10/19 |
|
Name |
HESTIA |
|
Type |
General cargo ship - Container ship heavy cargo |
|
IMO-number |
9411783 |
|
Call sign |
PCMO |
|
Flag |
The Netherlands |
|
Port of registry |
Ten Boer |
|
GT |
2.281 t |
|
DWT |
3.265 t |
|
NT |
1.170 t |
|
Number of 20ft containers |
104 |
|
Length |
88,97 m overall 84,99 m between perpendiculars |
|
Breadth |
11,80 m |
|
Draught |
5,05 m |
|
Air draft |
18,00 m ballast |
|
Freeboard |
1.732 mm |
|
Depth |
6,90 m moulded |
|
Speed |
10,5 knots |
|
Built |
2011 |
|
Launch date |
15/07/2011 |
|
Date of completion |
31/10/2011 |
|
Builder casco |
Nova Lodenice Shipyard (Usti nad Labem) Melnik Czech Republic |
|
Builder completion |
Bijlsma Shipyard B.V. (Veka) Sluisweg 13-16 8531 DJ Lemmer The Netherlands |
|
Yard number |
767 |
|
Hull material |
Steel |
|
Movable bulkhead |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8L20 - 4 stroke single acting 8 cylinder 200 x 240 mm combustion engine 1.440 kW / 1.958 hp at 1.000 rpm Manufacturer: Wärtsilä NSD, Zwolle - The Netherlands |
|
Gearbox |
1x Scana Volda ACG-62/450 reverse reduction gear 4,16:1 |
|
Propellers |
1x Screw propeller controllable pitch - aft at 241,0 rpm 4 blades - diameter 2.600 mm |
|
Boilers |
1x CHO 9,90 m² - 10,0 bar 1x CHR 27,00 m² - 10,0 bar |
|
Electric installations |
400/230 Volt - 50 HZ |
|
Shaft generator |
1x Stamford HCM534C23 generator 390 kVA / 312 kW at 1.500 rpm |
|
Generators |
1x Sisu Diesel 634DSBIG -6 cylinder 108 x 134 mm diesel engine 159 kW with Stamford UCM274H13 generator 175 kVA at 1.500 rpm Built: 2007 |
|
Emergency generator |
1x Sisu Diesel 320DSG- 3 cylinder 108 x 120 mm diesel engine 65 kW with Stamford UCM224C13 generator 81 kVA at 1.500 rpm Built: 2007 |
|
Bow thruster |
1x Omega 03100-2K - 282 kW at 1.780 rpm |
|
Number of holds |
1 Dimensions: 63,00 x 9,60 x 7,50 m |
|
Number of hatches |
1 Dimensions: 63,00 x 9,60 m |
|
Hold capacity |
Grain & bales: 158.985 ft³ / 4.531 m³ |
|
Hatch cover type |
Pontoon |
|
Strength |
Tanktop: 12,0 t/m² |
|
Tank capacities |
Ballast water: 1.458 m³ Potable water: 45 m³ Fuel oil: 192 m³ Lubricating oil: 13 m³ |
|
Manager |
Wagenborg Shipping BV Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Operator |
Wagenborg |
|
Owner |
Martin J. Langevoort en Teun A.P. Vogelij Ten Boer The Netherlands |
|
Registered owner |
C.V. Scheepvaartonderneming Hestia Delfzijl The Netherlands |
|
Last update |
30 September 2021 |
