| Brugge, Belgium 30 April 2023 |
 |
 |
 |
 |
|||
| Brugge 30/04/23 | Brugge 30/04/23 | Brugge 30/04/23 | Brugge 30/04/23 | |||
|
Name |
WILSON FLEX IV |
|
Type |
Multi-purpose dry cargo ship - Container ship |
|
IMO-number |
9911460 |
|
Call sign |
CQER4 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
GT |
2.995 t |
|
DWT |
Summer: 4.282 t Winter: 4.122 t |
|
NT |
1.563 t |
|
Number of 20ft containers |
On deck: 84 |
|
Length |
88,47 m overall 84,96 m between perpendiculars |
|
Breadth |
14,55 m extreme 14,00 m moulded |
|
Draught |
Summer: 5,70 m Winter: 5,58 m |
|
Keel to mast end |
26,83 m Lowered mast: 18,50 m |
|
Depth |
7,35 m moulded |
|
Speed |
Service: 10,10 knots Max: 13,7 knots |
|
Built |
2022 |
|
Keel laid |
28/06/2021 |
|
Launch date |
06/01/2022 |
|
Date of completion |
29/11/2022 |
|
Builder |
Dayang Offshore Equipment Co., Ltd. |
|
Yard number |
SH103 |
|
Hull material |
Steel |
|
Bulkheads positions |
20 |
|
Main engine |
1x ABC 6DZC-1000-167-A - 6 cylinder combustion engine 1.333 kW Manufacturer: Anglo Belgian Corporation NV, Gent - Belgium |
|
Propellers |
1x Fixed pitch mono-block propeller 4 blades - Diameter: 2950 mm |
|
Shaft generator |
1x Oswald TF36.55-24WWR_FS - 259kW |
|
Generators |
2x Perkins E70 TAG1M main diesel generatorsets each 129 kW at 1.800 rpm |
|
Emergency generator |
2x Perkins E70 TAG2M diesel generatorset 122 kW at 1.800 rpm |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
1 56,00 x 11,30 x 8,63 m |
|
Number of hatches |
1 60,80 x 10,05 m |
|
Hatch type |
Pontoon |
|
Max permitted loads |
Hatch covers: 2,5 t/m² Tanktop: 15,0 t/m² |
|
Tank capacities |
Water ballast: 1.838,6 m³ MGO: 181 m³ |
|
Anchor equipment |
Length: 440,00 m Diameter: 36 mm |
|
Crew |
7 |
|
Manager |
Wessels Reederei GmbH & Co. KG Industriestr. 12-14 49733 Haren/Ems Germany |
|
Operator |
Wilson ASA Damsgårdsveien 135 5160 Laksevåg Norway |
|
Registered owner |
RHAS 4 Schifffahrts UG (haftungsbeschränkt) & Co. KG Boschstraße 16 49733 Haren Germany |
|
Latest data adjustment |
08 May 2023 |
