Westerschelde 01 April 2017 |
 |
 |
 |
 |
 |
||||
| Westerschelde 01/04/17 | Westerschelde 01/04/17 | Vlissingen 10/05/19 | Vl 10/05/19 | Westerschelde 21/02/20 |
|
Name |
JS CAESAR |
|
Type |
Liquefied gas tanker - Fully pressurized LPG carrier |
|
Main products |
Propane - Butane - Propylene - Butadiene - Butylene - VCM - P.O. - Isopropylamine |
|
IMO-number |
9577991 |
|
Call sign |
9V9993 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
5.036 t |
|
DWT |
Summer: 4.986 t |
|
NT |
1.511 t |
|
Length |
99,85 m overall 92,43 m between perpendiculars |
|
Breadth |
17,42 m extreme |
|
Draught |
7,06 m |
|
Freeboard |
4.652 mm |
|
Depth |
11,70 m |
|
Speed |
14,0 knots laden |
|
Built |
2012 |
|
Keel laid |
09/04/2011 |
|
Launch date |
28/09/2011 |
|
Date of completion |
24/05/2012 |
|
Builder |
Nantong Sinopacific Offshore & Engineering Co., Ltd. Shanghai China |
|
Yard number |
DJ1001 |
|
Hull material |
Mild steel |
|
Hull type |
Double bottom |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 6L32/40 - 4 stroke 6 cylinder 320 x 400 mm combustion engine 3.000 kW / 4.076 bhp at 750 rpm |
|
Propellers |
1x Screw Propeller controllable pitch - aft at 147 rpm |
|
Boilers |
Exhaust boiler: Economiser CHF 123,00 m²- 10,0 bar Auxiliary boiler: CHR 19,00 m² - 10,0 bar |
|
Shaft generator |
1x 500 kVA - 400 kW |
|
Generators |
2x Diesel generatorsets each 538 kVA - 430 kW - 679 hp |
|
Emergency generator |
1x Diesel generatorsets 380 kVA - 304 kW - 461 hp |
|
Bow thruster |
1x 250 kW |
|
Number of cargo tanks |
2 Tank 1: cylindrial Tank 2: Bilobe |
|
Cargo tanks capacity |
100% / 98% Tank 1: 1.788 m³ / 1.752 m³ Tank 2: 3.221 m³ / 3.157 m³ Total: 5.010 m³ / 4.909 m³ |
|
Number of pumps |
3x Svanehoj deepwell cargo pumps each 150 m³/h |
|
Max. pressure |
18,6 bar |
|
Min. temp |
-10°C |
|
Tank capacities |
IFO: 685,6 m³ MGO: 176 m³ Fresh water: 218 m³ Water ballast: 1.929 m³ |
|
Anchor equipment |
Length: 495,00 m Diameter: 44 mm |
|
Lifting equipment |
1x Hose handling crane - SWL 4,0 t Outreach: 16,50 m |
|
Crew size |
16 |
|
Commercial manager |
Evergas |
|
Technical manager |
Hartmann Gas Carriers Germany GmbH & Co. KG Königstraße 23 D-26789 Leer Germany |
|
Registered owner |
Marina Aster Shipping Pte. Ltd. |
|
Latest data adjustment |
04 May 2020 |
