Westerschelde 26 February 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 30/12/17 | Westerschelde 30/12/17 | Terneuzen 16/08/19 | Spijkenisse 22/10/19 | Westerschelde 31/08/18 | ||||
|
Name |
JS ALULAR |
|
Type |
Liquefied gas tanker - Fully pressurized LPG carrier |
|
Products |
Butylene - VCM - P.O. - Isopropylamine |
|
IMO-number |
9578012 |
|
Call sign |
9V9995 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
5.036 t |
|
DWT |
Summer: 4.994 t |
|
NT |
1.511 t |
|
Length |
99,86 m overall 92,49 m between perpendiculars |
|
Breadth |
17,43 m extreme |
|
Draught |
7,06 m |
|
Keel to mast end |
32,55 m |
|
Freeboard |
4.652 mm |
|
Depth |
11,70 m |
|
Speed |
Service: 13,5 knots |
|
Built |
2012 |
|
Keel laid |
03/09/2011 |
|
Launch date |
28/12/2011 |
|
Date of completion |
21/08/2012 |
|
Builder |
Nantong CIMC Sinopacific Offshore & Engineering Co., Ltd. Shanghai China |
|
Yard number |
DJ1003 |
|
Hull material |
Mild steel |
|
Hull type |
Double bottom |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6L32/40 - 4 stroke 6 cylinder 320 x 400 mm combustion engine 3.000 kW / 4.076 bhp at 750 rpm Build: 17/11/2011 Builder: MAN Diesel & Turbo SE, 86224 Augsburg - Germany |
|
Propellers |
1xControllable pitch propeller - aft at 147 rpm |
|
Boilers |
Exhaust boiler: Economiser 19,00 m²- 10,0 bar Auxiliary boiler: CHO 19,00 m² - 10,0 bar |
|
Shaft generator |
1x 500 kVA - 400 kW |
|
Generators |
2x Diesel generatorsets each 564 kVA - 451 kW - 679 hp |
|
Emergency generator |
1x Diesel generatorsets 380 kVA - 304 kW - 461 hp |
|
Bow thruster |
1x 250 kW |
|
Number of cargo tanks |
2 |
|
Cargo tank capacity |
100 % / 98 % Tank 1: 1.788 m³ / 1.752 m³ Tank 2: 3.221 m³ / 3.157 m³ Total: 5.010 m³ / 4.909 m³ |
|
Number of pumps |
3x Svanehoj deepwell cargo pumps 150 m³/h each |
|
Tank capacities |
IFO 380 : 686 m³ MGO: 176 m³ Fresh water: 218 m³ Water ballast: 1.929 m³ |
|
Anchor equipment |
Length: 495,00 m Diameter: 44 mm |
|
Lifting equipment |
1x Crane - SWL 4,0 t Outreach: 16,50 m |
|
Crew complement |
16 |
|
Commercial manager |
Evergas Managemant AS |
|
Technical manager |
Hartmann Gas Carriers Germany GmbH & Co. KG Königstraße 23 D-26789 Leer Germany |
|
Registered owner |
Marina Daffodil Shipping Pte. Ltd. Care of Greenship Offshore Manager Pte Ltd . 14-06, Capital Square, 23, Church Street Singapore 049481 Republic of Singapore |
|
Renamed |
2023 Alular Republic of Singapore, Singapore City - Call sign: 9V9995 Owner: Dragon Alular Pte. Ltd., Lefkosia - Cyprus Operator: Hartmann Gas Carriers Germany GmbH & Co. KG |
|
Latest data adjustment |
11 March 2024 |
