Name |
RIO CADIZ |
|
Previous names |
2008 Completed as: Rio Cadiz 2008 - 12/2012 CSAV Lonquen |
|
Type |
Cellular containership |
|
IMO-number |
9360764 |
|
Call sign |
CQEP5 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flags |
2008 - 2021 Liberia, Monrovia - Call sign: A8OT2 |
|
GT |
40.807 t |
|
DWT |
Summer: 55.301,1 t |
|
NT |
24.257 t |
|
Number of 20ft containers |
4.334 |
|
Container capacity 14t |
2.810 |
|
Reefer capacity |
600 |
|
Length |
260,89 m overall 248,70 m between perpendiculars |
|
Breadth |
32,30 m extreme |
|
Draught |
13,00 m |
|
Depth |
19,30 m |
|
Forecastle |
124,85 m |
|
Bridge |
115,25 m |
|
Freeboard |
3.613 mm |
|
Speed |
Service: 24,2 knots |
|
Built |
2008 |
|
Keel laid |
14/08/2007 |
|
Launch date |
27/10/2007 |
|
Date of completion |
03/01/2008 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Jeollanam-do South Korea |
|
Yard number |
S322 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
|
|
|
Main engine |
1x MAN-B&W 8K90MC-C - 2 stroke single acting 8 cylinder 900 x 2.300 mm combustion engine 36.560 kW / 49.707 hp at 104,0 rpm Build: 2007 Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller- aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 7,85 bar Heating surface: 35,0 m² Heating surface: 490,0 m² Build: 2007 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) |
|
Electric Installations |
1x Plant 450 V - 1.687,5 kVA 1x Plant 450 V - 1.687,5 kVA 1x Plant 450 V - 2.493,75 kVA 1x Plant 450 V - 2.493,75 kVA 1x Plant 450 V - 187,5 kVA |
|
Generators |
2x HHI Himsen 6H25/33 diesel generatorsets each 1.350 kW / 1.687,5 kVA 2x HHI Himsen 9H25/33 diesel generatorsets each1.995 kW / 2.493,75 kVA |
|
Emergency generator |
1x Cummins 6CTA8.3-D(M) diesel generatorset 187,5 kVA |
|
Compressed air receivers |
2x Receivers each 11.000 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 2.000 litres - 7,0 bar 1 Receiver 250 litres - 7,0 bar |
|
Bow thruster |
1x 1.600 kW |
|
Tank capacities |
Ballast: 12.440 m³ |
|
Anchor equipment |
3x Anchors weight each 11.700 kg Length: 687,50 m Diameter: 84 mm |
|
Cargo gear |
Gearless |
|
Crew size |
27 |
|
Manager |
Wilhelmsen Ahrenkiel Ship Management GmbH & Co. KG |
|
Previous managers |
2008 - 2014 MPC Münchmeyer Petersen Steamship GmbH & Co. KG, Hamburg - Germany 2014 Ahrenkiel Steamship GmbH & Co. KG, Hamburg - Germany |
|
Registered owner |
Grisholmen AS c/o Fearnley Business Management AS Dronning Eufemias gate 8 0191, Oslo Norway |
|
Sister ships |
2008 Rio Charleston |
|
Renamed |
2023 MSC Basel V Portugal, Madeira - Call sign: CQEP5 Owner: Grisholmen AS Manager: MSC Shipmanagement Limited |
|
Latest data adjustment |
24 December 2023 |
