Antwerpen 12 October 2012 |
 |
 |
 |
||
| Antwerpen 12/10/12 | Malaga, Spain 05/03/18 | Zeebrugge 13/06/2021 |
|
Name |
MONZA EXPRESS |
|
Type |
Roll-On/Roll-Off carrier - Vehicle carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9451719 |
|
Call sign |
ZDJO7 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
36.711 t |
|
DWT |
Summer: 11.174 t |
|
NT |
11.013 t |
|
Length |
168,06 m overall 158,00 m between perpendiculars |
|
Breadth |
28,02 m extreme |
|
Draught |
8,72 m |
|
Depth |
30,65 m moulded |
|
Speed |
Service: 19,6 knots Eco: 15,0 knots Super slow: 12,5 knots |
|
Built |
2009 |
|
Keel laid |
25/05/2009 |
|
Date of completion |
21/10/2009 |
|
Builder |
Hyundai Mipo Dockyard Co Ltd. Ulsan South Korea |
|
Yard number |
8034 |
|
Hull material |
Steel - Part higher tensile steel |
|
Main engine |
1x Hyundai/MAN-B&W 7S50MC-C8 - 2 stroke 7 cylinder 500 x 2.000 mm combustion engine 15.799 bhp/ 11.620 kW at 127 rpm |
|
Propellers |
1x Fixed Pitch propeller |
|
Generators |
3x Main diesel generatorsets each 1.350 kW |
|
Bow thruster |
2x 900 kW, forward 1x 700 kW, aft |
|
Number of ramps |
2 |
|
Number of decks |
10 |
|
Deck area |
Deck 1: 1.736 m² Deck 2: 1.736 m² Deck 3: 2.322 m² Deck 4: 2.471 m² Deck 5: 3.551 m² Deck 6: 3.862 m² Deck 7: 3.642 m² Deck 8: 4.133 m² Deck 9: 4.127 m² Deck 10: 4.116 m² Total: 31.696 m² |
|
Liftable decks |
2 |
|
Mobile deck lifter |
1 |
|
Number of cars |
3.693 Basis RT43 standard cars / 4,125 m x 1;55 m) |
|
Ramp capacity |
Stern ramp: 30,00 x 7,00 m - SWL 120 t Side ramp: 21,00 x 4,10 m - SWL 22 t |
|
Crew size |
25 |
|
Crew |
19 |
|
Commercial manager |
Vroon BV Haven Westzijde 21 4511 AR Breskens The Netherlands |
|
Registered owner |
PCTC Express V BV Care of Vroon BV Lage Mosten 17 4822 HJ Breda The Netherlands |
|
Renamed |
05/2022 Neptune Phos Malta, Valletta - Call sign: 9HA5659 Reg. owner: Solon Shipping Co Ltd., Majuro - Marshall Islands |
|
Latest data adjustment |
16 July 2022 |
