| Vlissingen , The Netherlands 22 October 2011 |
 |
| Vlissingen 26/10/11 |
|
Name |
MTS VANTAGE |
|
Type |
Tug - Damen Shoabuster 2709 |
|
Functions |
Towing, mooring, anchor handling, dredging support |
|
IMO-number |
9585261 |
|
Call sign |
PCNE |
|
Flag |
The Netherlands |
|
Port of registry |
Terneuzen |
|
GT |
221 t |
|
NT |
69 t |
|
Length |
27,02 m overall 23,84 m between perpendiculars |
|
Breadth |
9,10 m |
|
Draught |
2,60 m |
|
Depth |
At sides: 3,60 m |
|
Speed |
Service: 11,0 knots Max.: 12,3 knots |
|
Built |
2011 |
|
Date of completion |
03.10.2011 |
|
Builder |
Damen Shipyard Hardinxveld |
|
Yard number |
571627 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar 3512BTTA - 4 stroke single acting 12 cylinder 170 x 190 mm diesel engines - 3.040 hp / 2.238 kW at 1.600 rpm Built: 2011 Builder: Caterpillar Tractor Co.,Mossville - USA |
|
Gear boxes |
2x Reintjes WAF 664 Ratio: 5.95:1 |
|
Propulsion |
2x Promarin fixed pitch propellers - at 269 rpm Diameter 2x 2.100 mm - 4 blades in Optima nozzles |
|
Generators |
2x Caterpillar C4.4TA - 4 cylinder 105 x 127 mm diesel engines each 75 kW / 117 hp at 1.500 rpm powered generators each 86,3 kVA Builder: Caterpillar Tractor Co.,Mossville - USA |
|
Bow thruster |
1x 200 hp hydraulically driven |
|
Bollard pull |
40,0 t |
|
Transfer pumps |
For water & fuel SIHI - 32 m³/h |
|
Fuel separator |
Alfa Laval |
|
Deck layout |
Anchor: 2x 225 kg Pool Deck crane: HEILA I40-4SL remote controlled - 5,3 t at 18 m Anchor winch: Ridderinkhof, waterfall Anchor handling/towing winch: 75 t – 100 t brake holding Towing wire: Tugger winch: 8 t - 30,00 m Stern deck: Hydraulic anchor pins x 3 Survey moon pool |
|
Tank capacities |
Fuel oil: 121,60 m³ Fresh water: 30,10 m³ Luboil: 3,90 m³ Hydraulic oil; 1,50 m³ |
|
Accommodation |
Heated and fully air conditioned living spaces for seven persons consisting of three single and two double crew cabin, a galley/mess & bathroom facilities |
|
Manager |
MTS Group Ltd. |
|
Operator |
MTS - Marine and Towage Services |
|
Owner |
Marine and Towage Services |
