| Vlissingen, The Netherlands 06 January 2012 |
 |
 |
 |
 |
|||
| Vlissingen 06/01/12 | Vlissingen 06/01/12 | Vlissingen 06/01/12 | Vlissingen 06/01/12 | |||
|
Name |
M.P.R.4 |
|
Type |
Tug - Eurocarrier 2209 - Utility vessel |
|
IMO-number |
9616577 |
|
Call sign |
PBZR |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
135 t |
|
DWT |
Summer: 187 t |
|
NT |
40 t |
|
Length |
21,60 m |
|
Breadth |
9,04 m |
|
Draught |
1,80 / 2,40 m |
|
Depth |
3,00 m |
|
Speed |
9,0 knots |
|
Built |
2011 |
|
Date of completion |
27.05.2011 |
|
Builder |
Neptune Shipyards B.V. |
|
Yard number |
397 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x Cummins QSK-19-M - 4 stroke single acting 6 cylinder 159 x 159 mm diesel engines - each 559 kW total 1.118 KW at 1.800 rpm Starter Type: Electrical starter Built: 2010 |
|
Gearbox |
2x Reverse reduction gears |
|
Propellers |
2x Fixed in forward nozzles at 395 rpm 4 blades - diameter 1.350 mm |
|
Generators |
2x Caterpillar C4.4 - 4 cylinder 105 x 127 mm diesel engines each 93,4 kW at 1.500 rpm Built: 2010 Manufacturer: Caterpillar Tractor Co. |
|
Bollard pull |
22 t |
|
Deck Load |
350 t |
|
Deck Area |
100 m³ |
|
Deck equipment |
Towing equipment aft: 1x Hydraulic winch 20 t Anchor-handling winch: 1x Hydraulic winch 50 t Tugger-Winch: 1x Hydraulic winch 10 t |
|
Tank capacities |
Fuel oil: 57 m³ Fresh water 30 m³ |
|
Lifting equipment |
1x Heila crane HLRM 140 - SWL 8,1 t at 14,09 m |
|
Other equipment |
Towing hook Push bow Bowroller Fuel supply pump Freshwater supply pump Anchor handling equipment |
|
Accommodation |
Heated and air conditioned for up to 5 persons |
|
Operator |
Marine Project Rotterdam BV |
|
Owner |
Multicat Marine Projects Rotterdam BV Rotterdam |
