Vlissingen 15 April 2012 |
 |
 |
 |
||
| Vlissingen 15/04/15 | Vlissingen 15/04/15 | Vlissingen 21/09/15 | ||
|
Name |
M.P.R.3 |
|
Type |
Tug - Special service / Multi purpose ship |
|
IMO-number |
9611539 |
|
Call sign |
PCKT |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
312 t |
|
NT |
93 t |
|
Length |
31,90 m |
|
Breadth |
11,00 m |
|
Draught |
2,70 m |
|
Freeboard |
1.132 mm |
|
Depth |
3,50 m |
|
Speed |
10,0 knots |
|
Built |
2011 |
|
Date of completion |
22/07/2011 |
|
Builder casco |
Shipyard Neptune Aalst Nederland |
|
Builder Completion |
Neptune Marine Service BV Hardinxveld Giessendam The Netherlands |
|
Yard number |
393 |
|
Hull material |
Steel |
|
Main engine |
2x Caterpillar C32 Acert electronic - 4 stroke 12 cylinder 145 x 162 mm combustion engines total 1.940 kW / 2.636 hp at 1.800 rpm Starter type: Electrical starter Builder: Caterpillar Inc. |
|
Gearboxes |
Twin disc reduction |
|
Propellers |
2x Screw propeller solid Diameter 1.700 mm in forward nozzles |
|
Generators |
2x Caterpillar C9 - 6 cylinder 112 x 149 mm diesel engine each 189 kW at 1.500 rpm connected with Leroy Somer LSAM46.2L9 generator each 250 kVA 1x Caterpillar C4.4 - 4 cylinder 105 x 127 mm diesel engine 57 kW at 1.500 mm connected with Leroy Somes LSAM43.2L8 generator 65 kVA Built: 2010 Builder: Caterpillar Tractor Co. |
|
Bow thruster |
360⁰ Bow thruster 280 kW 360⁰ Stern thruster 438 KW |
|
Deck load |
6,0 t/m² |
|
Deck area |
200 m² |
|
Bollard pull |
34 t |
|
Winches |
80 t Anchor handling winch 50 t Towing winch 10 t Tugger winch |
|
Tank capacities |
Fuel oil: 153 m³ Fresh water: 47 m³ |
|
Other equipment |
Towing hook Push bow Bow /stern roller Wheelhouse winch controls Fuel supply pump Freshwater supply pump Anchor handling equipment Forward/aft AHT pins/ hydraulic stopper |
|
Lifting equipment |
1x Heila HLRM Crane 230-4SL 10.300 kg @ 16,30 m 12.200 kg @ 14,40 m 15.400 kg @ 12,23 m 18.900 kg @ 10,06 m 24.400 kg @ 7,89 m 1x Heila HLRM Crane 140 10.000 kg @ 12,17 m 12.500 kg @ 10,01 m 18.000 kg @ 7,83 m 26.000 kg @ 5,67 m |
|
Accommodation |
Heated and Air-conditioned up to 11 persons |
|
Communication |
V-sat Iridium 2 DSC VHF radios Inmarsat c terminal Voip phone GSM phone |
|
Navigation equipment |
Magnetic compass GPS compass Daylight viewing radars Speed log Echo sounder Electronic chart Plotter Watch keeping alarm AIS DGPS navigator NAVTEX Talk back unit |
|
Owner |
Marine Projects Fortunaweg 76 3113 AN Schiedam The Netherlands |
|
Registered owner |
Multicat M.P.R. 3 B.V. |
|
Renamed |
09/2020 Sili Gwer Saint Vincent and the Grenadines, Kingstown - Call sign: J8B6002 Owner: Dermor Inc. Manager: Llyr Marine NL B.V - the netherlands |
|
Latest data adjustment |
03 February 2024 |
