Westerschelde 11 April 2019 |
 |
| Westerschelde 03/04/19 |
|
Name |
BOW COMPASS |
|
Previous names |
2009 - 2017 Argent Eyebright |
|
Type |
Chemical and oil product tanker |
|
IMO-number |
9412737 |
|
Call sign |
LACQ8 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
2009 - 2017 Republic of Panama, Panama City - Call sign: 3FKM7 |
|
GT |
19.440 t Suez: 20.141 t |
|
DWT |
Summer: 33.608,83 t |
|
NT |
9.793 t Suez: 18.576 t Panama: 18.440 t |
|
Light ship |
7.965 t |
|
Length |
170,00 m overall |
|
Breadth |
26,60 m extreme |
|
Draught |
Max: 11,32 m |
|
Keel to top of mast |
40,94 m |
|
Speed |
14,8 knots |
|
Built |
2009 |
|
Date of completion |
04/11/2009 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. Hachinohe Japan |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x Mitsubishi 6UEC52LS - 2 stroke single acting 6 cylinder combustion engine 7.980 kW at 120,0 rpm Manufacturer: Akasaka Diesel Co.Ltd., Shizuoka - Japan |
|
Propellers |
1 |
|
Generators |
3x main diesel generatorsets each 620 ekW 450 Volt 60 Hz |
|
Number of cargo tanks |
16 |
|
Cargo tank capacity |
Liquid: 37.994 m³ |
|
Number of pumps |
16x Cargo pumps each 330 m³/h |
|
Manifolds |
Summer waterline to manifold: 7,63 m Normal ballast waterline to manifold: 11,85 m Rail to manifold: 5,70 m Bow to centre of manifold: 87,70 m |
|
Tank capacities |
Fuel oil: 1.837 m³ Fresh water: 936 m³ |
|
Lifting equipment |
1x Hose handling crane |
|
Crew |
21 |
|
Manager |
Odfjell Management AS Conrad Mohrs veg 29 5072 Bergen Norway |
|
ISM manager |
Thome Croatia d.o.o. |
|
Previous managers |
Tokyo Marine Co.Ltd., Tokyo - Japan |
|
Registered owner |
Odfjell Chemical Tankers AS Conrad Mohrs veg 29 5072 Bergen Norway |
|
Previous owners |
2009 - 2017 SS Harmony Sg SA, Osaka - japan |
|
Latest data adjustment |
22 July 2021 |
