Westerschelde 08 October 2017 |
 |
 |
|
| Westerschelde 17/10/17 | Westerschelde 17/10/17 | |
|
Name |
DUKE-I |
|
Previous names |
2002 - 12/2012 Antigano |
|
Type |
Chemical tanker |
|
IMO-number |
9228784 |
|
Call sign |
3FBO |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
2002 - 2012 Italy, Livorno |
|
GT |
24.997 t |
|
DWT |
Summer: 39.999 t |
|
NT |
10.170 t Suez: 23.219 t Panama: 20.900 t |
|
Displacement |
48.954 t |
|
Length |
175,93m overall 168,00 m between perpendiculars |
|
Breadth |
31,00 m extreme |
|
Draught |
Summer: 11,60 m |
|
Freeboard |
5.413 mm |
|
Depth |
17,00 m moulded |
|
Speed |
Max: 16,3 knots |
|
Built |
2002 |
|
Date of completion |
28/02/2002 |
|
Builder |
Hyundai Mipo Dockyard Co. Ltd. |
|
Yard number |
4 |
|
Hull material |
Steel/ordinary |
|
Hull type |
Double hull |
|
Bulkheads |
13 |
|
Continuous decks |
1 |
|
Main engine |
1x 6S50MC - 6 cylinder combustion engine 11.640 bhp / 8.679 kW Builder HHI Engine & Machinery Div. |
|
Propellers |
1x Fixed pitch propeller |
|
Generators |
3x Main diesel generatorsets each 720 kW |
|
Cargo tank capacity 98% |
44.193 m³ |
|
Slop tank capacity 98% |
1.629 m³ |
|
Segregations |
6 |
|
Pumps |
12x Cargo pumps 450 m³ each 2x Cargo pumps 100 m³ each 1x Cargo pump 70 m³ |
|
Manifolds |
Bow centre manifolds: 87,00 m |
|
Tank capacities |
Fuel oil: 1.761 m³ Fresh water: 218 m³ Ballast water: 19.963 m³ |
|
Lifting equipment |
1x Crane - SWL 10,0 t |
|
Manager |
UPT United Product Tankers GmbH & Co. KG |
|
Operator |
Sea World Mangement SAM |
|
Owner |
Basford Shipping Inc. |
|
Latest data adjustment |
13 August 2018 |
