Westerschelde 22 October 2016 |
 |
 |
 |
 |
|||
| Westerschelde 22/10/16 | Antwerpen 30/01/18 | Antwerpen 30/01/18 | Antwerpen 30/01/18 | |||
|
Name |
KEY MARIN |
|
Previous names |
2005 - 08/2006 Serra D 08/2006 - 12/2008 Vedrey Heden 12/2008 - 2015 Brøvig Marin |
|
Type |
Oil/Chemical tanker |
|
IMO-number |
9297228 |
|
Call sign |
ZDHP4 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
2.262 t |
|
DWT |
Summer: 3.450,28 t |
|
NT |
1.040 t |
|
Length |
88,22 m overall |
|
Breadth |
13,00 m |
|
Draught |
5,94 m |
|
Depth |
7,20 m |
|
Speed |
Service: 13,0 knots Max: 14,5 knots |
|
Built |
2005 |
|
Date of completion |
08/04/2005 |
|
Builder |
Turkter Tersane ve Deniz Isl. A.S. Tuzla - Istanbul Turkey |
|
Yard number |
11 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.850 kW / 2.515 hp at 750 rpm Builder: Caterpillar Motoren GmbH & Co. KG - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Shaft generator |
1x 600 kW - 440/220 Volt 60 Hz |
|
Generators |
3x Caterpillar 3406C-TA engine coupled with generator each 325 kW - 440/220 Volt 60 Hz |
|
Bow thruster |
1x 280 kW / 381 bhp |
|
Number of cargo tanks |
10 |
|
Cargo tanks capacity 98% |
Tank 1P: 297,7 m³ Tank 1S: 296,5 m³ Tank 2P: 363,5 m³ Tank 2S: 366,3 m³ Tank 3P: 416,4 m³ Tank 3S: 418,2 m³ Tank 4P: 382,4 m³ Tank 4S: 390,2 m³ Tank 5P: 365,9 m³ Tank 5S: 365,1 m³ Total: 3.750 m³ incl. sloptanks |
|
Pumps |
10x Cargo pumps each 150 m³/h |
|
Crew size |
12 |
|
Manager |
Sea Tank Chartering AS Skuteviksboder 22 N-5035 Bergen NorwaySea Tank Chartering AS Skuteviksboder 22 N-5035 Bergen Norway |
|
Operator |
Columbia Shipmanagement Ltd. Columbia House, 21 Spyrou Kyprianou Avenue 4042 Limassol Cyprus |
|
Owner |
Key Shipping AS |
|
Previous names & owners |
2005 - 08/2006 Serra D - Admarin Denizcilik Sanayi ve Ticaret Ltd Sti. 08/2006 - 12/2008 Vedrey Heden - Whiteport Shipping Co Ltd. 12/2008 - 2015 Brovig Marin - Kokoda Tankers AS |
|
Latest data adjustment |
30 January 2020 |
