Antwerpen 29 March 2014 |
 |
| Westerschelde 04/03/19 |
|
Name |
SEACOD |
|
Type |
Oil products tanker - Suitable for carriage of various oil products |
|
IMO-number |
9352315 |
|
Call sign |
DDPW |
|
Flag |
Germany |
|
Port of registry |
Bremen |
|
GT |
26.548 t |
|
DWT |
Summer: 40.558,5 t |
|
NT |
10.288 t |
|
Length |
188,18 m overall 1179,50 m registered |
|
Breadth |
32,23 m extreme |
|
Draught |
11,00 m |
|
Keel to mast end |
44,60 m |
|
Forecastle |
13,56 m |
|
Depth |
17,05 m |
|
Speed |
16,3 knots |
|
Built |
2006 |
|
Keel laid |
09/02/2006 |
|
Launch date |
30/06/2006 |
|
Date of completion |
31/10/2006 |
|
Builder |
Lindenau GmbH Schiffswerft & Maschinenfabrik Christianspries 30 24159 Kiel Federal Republic of Germany |
|
Yard number |
S 273 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
10 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 8L58/64 CD - 4 stroke 8 cylinder 580 x 640 mm combustion engine 11.200 kW / 15.228 hp at 428 rpm Year of manufacture: 2006 Manufacturer: MAN Diesel & Turbo SE Stadtbachstr. 1 86153 Augsburg Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 116 rpm |
|
Boilers |
1x Steam boiler, exhaust gas heated - 12,0 bar Heating surface: 92,0 m² 1x Steam boiler, oil fired - 12,0 bar Heating surface: 170,0 m² Year of manufacture: 2006 Manufacturer: Alfa Laval Aalborg A/S Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
3x Plants each 400/230 V - 1.425 kVA 1x Plant 400 V - 1.700 kVA 1x Plant 400 V - 200 kVA 1x Plant 24 V - 170 Ah 2x Plants each 24 V - 170 Ah 2x Plants each 24 V - 170 Ah |
|
Shaft generator |
1x 1.700 kVA |
|
Generators |
3x Wärtsilä A6L20 main diesel generatorsets each 1.425 kVA |
|
Emergency generator |
1x MAN D 2866 TE diesel generatorset 200 kVA |
|
Batteries |
2x Batteries for automation each 170 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 1.000 litres - 8,0 bar |
|
Bow thruster |
1x Transverse thruster 1.250 kW, forward |
|
Number of tanks |
10 + 2 slop tanks |
|
Cargo tank capacity |
42.894 m³ |
|
Number of pumps |
10x Cargo pumps each 600 m³/h |
|
Tank capacities |
Ballast: 20.440,07 m³ |
|
Anchor equipment |
3x Anchors weight each 8.300 kg Chain length: 632,50 m Diameter: 70 mm |
|
Crew size |
29 |
|
ISM & commercial manager |
German Tanker Shipping GmbH & Co., KG Hans-Böckler-Str. 50 28217 Bremen Federal Republic of Germany |
|
Registered owner |
TMS "SEACOD" GmbH & Co., KG Hans Böckler Str. 50 28217 Bremen Federal Republic of Germany |
|
Latest data adjustment |
19 September 2022 |
