| Westerschelde 24 November 2011 |
 |
| Westerschelde 24/11/11 |
|
Name |
MALOU THERESA |
|
Previous names |
Umay Ece |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9428437 |
|
Call sign |
9HGA9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.289 t |
|
DWT |
Summer: 7841,87 t |
|
NT |
2.415 t |
|
Length |
122,66 m overall 115,31 m between perpendiculars |
|
Breadth |
17,20 m |
|
Draught |
7,00 m |
|
Air draft |
30,75 m |
|
Freeboard |
1.940 mm |
|
Speed |
14,0 knots |
|
Built |
2003 |
|
Date of completion |
15.07.2008 |
|
Builder |
Deniz Kuvvetleri Istanbul Tersanesi Komutanligi |
|
Yard number |
03 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32C - 4 stroke 8 cylinder 320 x 480 mm diesel engine - 4.000 kW / 5.435 hp at 600 rpm Built: 2007 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Electrical propulsion gen. |
1x 1.012kW - 440 Volt |
|
Propelling system |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO Aalborg Industries 57,00 m² - 13,0 bar |
|
Generators |
3x MAN main diesel generatorsets each 775 kVA - 620 kW - 842 hp |
|
Emergency generator |
1x MAN diesel generatorset 110 KW |
|
Bow thruster |
450 kW |
|
Tank capacity 98% |
8.397,07 m³ + 2x 49 m³ in 2 deck slop tanks |
|
Segregation |
14 |
|
Manifolds |
Manifold to deck: 3.050 mm Manifold to stern: 58,06 m Manifold to bow: 64,60 m Manifold to rail: 2.260 mm |
|
Cargo pumps |
12x Deepwell pumps each 30 m³/h 10 mlc 1x Deepwell pump 100 m³/h 10 mlc 1x Centrifugal pump 50 m³/h - 10,0 bar |
|
Loading rate |
360 m³/h per tank 150 m³h cargo tank |
|
Discharging rate |
1.800 m³/h |
|
Heating capacity |
2.000 KW |
|
Tank cleaning system |
26x Scanjed fixed BW machines - 2x 2000 KW heater |
|
Tank capacities |
Fuel oil: 427 m³ Diesel oil: 79 m³ Water ballast: 3.640 m³ |
|
Lifting equipment |
1x Crane - SWL 3,0 t x 15,00 m |
|
Manager |
Bsm Singapore Republic of Singapore |
|
Operator |
Bernhard Schulte Shipmanagement (Singapore) Pte Ltd. Republic of Singapore |
|
Owner |
Malou Theresa K/S |
