Elveba - IMO 9367918

Name

ELVEBA

Type

Oil products tanker
Deep sea bunker ship

IMO-number

9367918

Call sign

ONEC

Flag

Belgium

Port of registry

Antwerpen

GT

2.455 t

DWT

Summer: 3.840 t

NT

1.089 t

Length

99,95 m overall
96,65 m between perpendiculars

Breadth

14,45 m overall

Draught

Summer: 4,41 m

Freeboard

1.600 mm

Depth

5,91 m

Built

2006

Date of completion

13.06.2006

Builder casco

Astrakhanskiy Korabel
Astrakhan
Russia
Yard number: 901

Builder completion

Scheepsreparatiebedrijf De Gerlien – Van Tiem BV
Druten
The Netherlands
Yard number: 267

Hull material

Steel

Hull type

Double hull

Watertight compartments

9

Number of Cont. decks

1

Main engine

2x ABC 6 MDZC - 6 cylinder 256 x 310 mm diesel engines - each 1.104 kW / 1.500 hp at 800 rpm total power 2.208 kW / 3.000 hp
Built: 2005
Builder:Anglo Belgian Corporation NV. Gent - Belgium

Number of screws

2x Screw propeller solid - at 266 rpm

Boiler

1x CHO 49,03 m² - 9,0 bar

Electrical installation

Power voltage: 440 V
Lighting voltage: 220 V
Frequency: 50 Hz

Generators

2x Scania type DI 12 diesel generatorsets each 399 kVA
2x Sisu type 620 DSRIG diesel generatorsets each 120 kVA

Emergency generator

1x Sisu 420 DG diesel generatorset 41 kVA

Cargo capacity

3.620 m³

Rubber fenders

Diameter: 2,00 m

Number of tanks

12

Tank capacities

Fresh water: 70 m³
Diesel oil tank:180 m³
Ballast: 1.800 m³

Free fall life-boat

Ned-Deck Marine
Barneveld
The Netherlands

Manager

Elveba Bunkering N.V.
Vosseschijnstraat
Kaai 140
2030 Antwerpen
Belgium

Owner

Elveba Bunkering N.V.
Vosseschijnstraat
Kaai 140
2030 Antwerpen
Belgium

Renamed

05.2014 New Jersey
