| Westerschelde 08 February 2012 |
 |
| Westerschelde 08/02/12 |
|
Name |
CHEMSTAR DUKE |
|
Type |
Oil / Molasses / Chemical |
|
IMO-number |
9185877 |
|
Call sign |
H3IR |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
11.951 t |
|
DWT |
Summer: 19.441 t |
|
NT |
5.765 t |
|
Length |
147,83 m overall 141,00 m between perpendiculars |
|
Breadth |
24,20 m registered |
|
Draught |
9,23 m |
|
Moulded L x B x D |
141,00 x 24,20 x 12,80 m |
|
Registered L x B x D |
141,21 x 24,20 x 12,80 m |
|
Air draft |
32,50 m lightship |
|
Keel to mast |
38,52 m |
|
Freeboard |
Summer: 3.614 mm |
|
Depth |
12,80 m moulded |
|
Speed |
Trial: 16,2 knots Service: 14,7 knots |
|
Built |
2000 |
|
Keel laid |
27.08.1999 |
|
Launch date |
14.12.1999 |
|
Date of completion |
26.06.2000 |
|
Builder |
Shin Kurushima Hiroshima Dockyard |
|
Yard number |
5008 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi 7UEC45LA - 2 stroke single acting 7 cylinder 450 x 1.350 mm diesel engine - 6.178 kW / 8.400 bhp at 158,0 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works |
|
Propellers |
1x Fixed pitch propeller |
|
Propeller shaft |
Oil lubrication shaft without monitoring device |
|
Boilers |
1x Auxiliary vertical boiler - 9,8 bar Evaporation: 16,02 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
4x Diesel generators each 1.290 kVA |
|
Number of tanks |
22x Wing tanks |
|
Cargo separations |
22 |
|
Cargo capacity |
Liquid: 21.853 m³ |
|
Pumps |
20x Pumps with a total capacity of 4.000 m³ |
|
Manifolds |
Manifold height above deck: 2,69 m Distance from bow to centre manifold: 74,03 m |
|
Tank capacities |
Fuel oil: 1.051 m³ Fresh water: 302 m³ Water ballast: 8.138 m³ |
|
Manager |
Iino Marine Services Co., Ltd. |
|
Owner |
Fukuman Panama, S.A. |
|
Renamed |
08.2012 Au Taurus |
