| Westerschelde 01 March 2019 |
 |
 |
 |
 |
|||
| Westerschelde 01/03/19 | Westerschelde 24/08/14 | Westerschelde 30/07/14 | Antwerpen 15/07/12 | |||
|
Name |
BALTIC FROST |
|
Previous names |
2006 - 2011 Baltic Front |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9327401 |
|
Call sign |
9HA2868 |
|
Flag |
Malta |
|
Previous flags |
2006 - 2011 Cyprus, Limassol- Call sign: C4JX2 |
|
Port of registry |
Valletta |
|
GT |
23.337 t Suez: 24.521,16 t |
|
DWT |
37.100 t |
|
NT |
10.107 t Suez: 20.829,68 t Panama: 19.446 t |
|
Displacement |
Summer: 46.003 t |
|
Length |
182,55 m overall 176,08 m between perpendiculars |
|
Breadth |
27,34 m extreme |
|
Draught |
10,85 m |
|
Air draft |
Lightship: 42,530 m Normal ballast: 38,19 m At loaded summer deadweight: 33,773 m |
|
Keel to masthead |
44,99 m |
|
Freeboard |
Summer: 5.514 mm |
|
Depth |
16,70 m moulded |
|
Built |
2006 |
|
Keel laid |
20/07/2006 |
|
Launch date |
20/10/2006 |
|
Date of completion |
07/12/2006 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Bangeo-Dong Dong-gu 682-712 Ulsan Republic of Korea |
|
Yard number |
0441 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse bulkheads: 9 Longitudinal bulkheads: 3 |
|
Main engine |
1x MAN-B&W 7S50MC-C - 2 stroke 7 cylinder 500 x 2.000 mm combustion engine 11.060 kW / 15.050 hp at 127,0 rpm Manufacturer: Bryanskiy Mach. Zavod |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, vertical shell type Mission OL - 8,8 MPa Builder: Aalborg Industries A/S 1x Auxiliary boiler, exhaust gas water tube EM12DD09A2 Builder: KangRim Industries. Co., Ltd. |
|
Generators |
3x Himsen 6H21/32 diesel generatorsets each 730 kW Builder: Hyundai Heavy Ind. Co. Ltd. |
|
Emergency generator |
1x Cummins L-10 diesel generatorset |
|
Number of tanks |
12 + 2 slop tanks |
|
Cargo Capacity 98% |
Seg#1: 6.035,6 m³ No. 1 (P & S) Seg#2: 7.176,2 m³ No. 2 (P & S) Seg#3: 7.194,6 m³ No. 3 (P & S) Seg#4: 7.194,6 m³ No. 4 (P & S) Seg#5: 7.194,6 m³ No. 5 (P & S) Seg#6: 6.341,8 m³ No. 6 (P & S) Seg#7: 878,6 m³ Slop tanks (P & S) |
|
Total cubic capacity 98% |
41.137,4 m³ excluding slop tanks |
|
Slop tanks capacity 98% |
942,0 m³ |
|
Maximum loading rate |
1.837,5 m³/h |
|
Pumps |
Cargo pumps: 10x Centrifugal each 500 m³/h 2x Centrifugal each 320 m³/h 2x Centrifugal each 150 m³/h Ballast pumps: 2x Centrifugal each 750 m³/h |
|
Manifolds |
Bow to centre manifold: 92,58 m Stern to centre manifold: 89,97 m Distance bridge front to centre of manifold: 56,34 m Distance between cargo manifold centres: 2.000 mm Distance ships rail to manifold: 4.400 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 850 mm Distance main deck to centre of manifold: 2.100 mm |
|
Tank capacities |
Fuel oil: 1.261,00 m³ Diesel oil: 207,00 m³ Water ballast: 18.455,60 m³ Lub oil: 101,60 m³ Fresh water: 931,70 m³ Hydraulic oil: 15,70 m³ |
|
Anchor equipment |
Length: 605,10 m Diameter: 66 mm |
|
Lifting equipment |
1x Engine room crane - SWL 2,0 t 1x Hose handling crane - SWL 10,0 t 1x Provision & rescue boat crane - SWL 10,0 t Manufacturer: Dongnam Marine Crane Co., Ltd. 1x Provision crane - SWL 2,0 t Manufacturer: Haen Machniry Ind. Co., Ltd. |
|
Commercial manager |
Interorient Marine Services (Cyprus) Ltd. 142, Fragklinou Rousvelt Street 3011 Limassol Cyprus |
|
ISM manager |
Interorient Marine Services (Germany) GmbH & Co. KG Kajen 12 DE-20459 Hamburg Germany |
|
Previous managers |
2008 - 2011 Interorient Marine Services Ltd., CY-3011 Limassol - Cyprus 2006 - 2008 Interorient Navigation Co. Ltd., 3011 Limassol - Cyprus |
|
Operator |
Norient Product Pool Hellerup Denmark |
|
Registered owner |
Baltic Frost LLC Care of Interorient Marine Services Ltd. 142, Fragklinou Rousvelt Street 3011 Limassol Cyprus |
|
Previous owners |
2006 - 2011 B. Front Shipping Co., Ltd. - Cyprus |
|
Latest data adjustment |
28 August 2022 |
