Antwerpen 06 February 2020 |
 |
| Antwerpen 06/02/20 |
|
Name |
LADY DENIZ |
|
Previous names |
2009 - 2018 Island Green |
|
Type |
General cargo vessel - Carriage of dangerous goods |
|
IMO-number |
9550412 |
|
Call sign |
V7BY5 |
|
Flag |
Marshall islands |
|
Port of registry |
Majuro |
|
Previous flags |
2009 - 2018 Hong Kong, China- Call sign: VRFU3 |
|
GT |
18.096 t |
|
DWT |
Summer: 28.742 t |
|
NT |
9.649 |
|
Displacement |
35.634 t |
|
Length |
169,54 m overall 160,40 m between perpendiculars |
|
Breadth |
27,00 m moulded |
|
Draught |
Max: 9,76 m |
|
Freeboard |
4.081 mm |
|
Depth |
13,80 m moulded |
|
Speed |
16,3 knots |
|
Built |
2009 |
|
Keel laid |
23/06/2006 |
|
Delivery date |
26/10/2009 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Imabari Shipyard 4-52 Koura-Cho 1-Chome Imabari City, 799-2195 Japan |
|
Yard number |
695 |
|
Hull material |
Steel |
|
Main engine |
1x 6S42MC - 2 stroke 6 cylinder 420 x 1.700 mm combustion engine 6.480 kW at 136,0 rpm Manufacturer: Makita Corporation |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Composite auxiliary boiler - 8,0 bar Manufacturer: Miura Co. Ltd. |
|
Generators |
3x Yanmar 6EY18AL combustion engine each 500 kW connected with generators each 440 kW |
|
Cargo hold capacity |
Bale: 35.401,98 m³ Grain: 37.181,09 m³ |
|
Tank capacities |
Fuel oil: 1.689,85 m³ Ballast: 9.520,46 m³ Lube oil: 75,67 m³ Fresh water: 260,76 m³ Diesel oil: 21,88 m³ |
|
Lifting equipment |
1x General use crane port - SWL 1,5 t 1x General use crane port - SWL 0,9 t |
|
Cargo gear |
4x Deck cranes - SWL 30,5 t each |
|
Registered owner |
Lady Deniz Shipping Ltd. |
|
Latest data adjustment |
10 May 2020 |
