Westerschelde 02 February 2019 |
 |
| Westerschelde 27/05/17 |
|
Name |
ASPEN |
|
Previous names |
2000 Launch as: Heinrich G 12/2000 - 04/2006 Barbel P 04/2006 - 08/2007 Bukanier |
|
Type |
Multi-purpose carrier - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9195389 |
|
Call sign |
PHLN |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
Previous flags |
Gibraltar, Gibraltar - Call sign: ZDEI7 |
|
GT |
2.301 t |
|
DWT |
Summer: 3.171 t |
|
NT |
1.289 t |
|
Number of 20ft containers |
132 |
|
Reefer capacity |
12 on deck |
|
Length |
82,50 m overall 78,15 m between perpendiculars |
|
Breadth |
12,40 m extreme |
|
Draught |
Max: 5,31 m |
|
Depth |
6,70 m |
|
Speed |
11,5 knots laden 12,0 knots ballast 10,0 knots economic |
|
Built |
2000 |
|
Keel laid |
29/06/1998 |
|
Launch date |
02/08/2000 |
|
Date of completion |
01/12/2000 |
|
Builder casco |
Daewoo Mangalia Heavy Industries S.A. Mangalia Rumania Yard number: 1019 |
|
Builder completion |
Pattje Shipyards B.V. Waterhuizen The Netherlands Yard number: 419 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Movable bulkheads |
2 can be placed in 7 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.800 kW/ 2.446 hp at 750 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
300 kW |
|
Generators |
2x MAN D2866E main diesel generatorsets each 141 kVA - 113 kW - 154 hp |
|
Emergency generator |
1x Diesel generatorset 141 kVA - 113 kW - 154 hp |
|
Bow thruster |
1x fixed 200 kW at 1.470 rpm |
|
Number of holds |
1x Boxshaped 56,25 x 10,20 x 8,45 m |
|
Cargo hold capacity |
Grain: 4.782 m³ - 168.875 ft³ |
|
Hold ventilation |
6x Air-changes per hour |
|
Number of hatches |
1 |
|
Hatch type |
Pontoon type, moved by gantry crane |
|
Tank capacities |
Ballast: 1.360 m³ HFO: 216,9 m³ MDO: 17,2 m³ Fresh water: 46 m³ |
|
Anchor equipment |
Length: 440,00 m |
|
Lifting equipment |
Diameter: 32 mm |
|
Accommodation |
12 persons, 8 cabins |
|
Manager |
Marin Ship Management B.V. Hogelandsterweg 14 9936 BH Farmsum The Netherlands |
|
Previous managers |
12/2000 - 08/2007 Briese Schiffahrts & Co. K.G., Gibraltar - Gibraltar |
|
Registered owner |
MF Ship II B.V. Delfzijl The Netherlands |
|
Group |
MF Shipping group |
|
Previous names & owners |
12/2000 - 04/2006 Barbel P - Hubertgat Shipping Co. Ltd. 04/2006 - 08/2007 Bukanier - Hubertgat Shipping Co. Ltd. |
|
Latest data adjustment |
11 April 2020 |
