Antwerpen 17 September 2018 |
|
Name |
MARIE |
|
Previous names |
2002 - 03/2005 Wani River 03/2005 - 07/2006 Harleriff 07/2006 - 2017 Fehn Mirage |
|
Type |
General cargo ship - Equipped for carriage of containers |
|
IMO-number |
9252929 |
|
Call sign |
ONJC |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flags |
2002 - 2017 Gibraltar - Call sign: ZDFC3 |
|
GT |
2.061 t |
|
DWT |
Summer: 2.974 t |
|
NT |
1.161 t |
|
Number of 20ft containers |
118 |
|
Reefer plug |
6 |
|
Length |
88,47 m overall 84,68 m between perpendiculars |
|
Breadth |
11,35 m registered |
|
Draught |
Summer: 4,94 m |
|
Air draft |
25,10 m full ballast |
|
Forecastle |
6,46 m |
|
Poop |
16,80 m |
|
Freeboard |
1.460 mm |
|
Depth |
6,40 m moulded |
|
Speed |
10,5 knots |
|
Built |
2002 |
|
Keel laid |
29/06/1998 |
|
Launch date |
16/01/2002 |
|
Date of completion |
04/2002 |
|
Builder |
Slovenske Lodenice Komarno A.S. |
|
Yard number |
1712 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull Partly double bottom |
|
Watertight bulkheads |
4 |
|
Movable bulkheads |
2x Moveable bulkheads, full hold height, 10 positions |
|
Continuous decks |
1 |
|
Main engine |
1x Deutz SBV 6 M 628 - 4 stroke single acting 6 cylinder 240 x 280 mm diesel engine 1.125 kW / 1.529 hp at 900 rpm Year of manufacture: 2001 Manufacturer: Deutz MWM Motoren-Werke Mannheim AG |
|
Propellers |
1x Solid propeller aft at 264 rpm |
|
Boilers |
Water heater, oil fired - 5,0 bar |
|
Electric installations |
1x 380/220 V - 350 kVA 1x 380 V - 116 kVA 1x 380 V - 100 kVA |
|
Shaft generator |
1x 116 kVA - 93 KW |
|
Generators |
2x Main diesel generatorsets each 175 kVA - 140 kW - 219 hp |
|
Emergency generator |
1x Diesel generatorset 100 kVA- 80 kW - 128 hp |
|
Compressed air receivers |
2x Receivers, each 125 litres - 30,0 bar 1x Receiver 10 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 'JASTRAM' - 130 kW, forward |
|
Number of holds |
1x Box type 57,50 m x 9,00 m x 8,04 m |
|
Cargo capacity |
Grain: 4.165 m³ |
|
Number of hatches |
1 Length: 57,50 m |
|
Hatch type |
Folding type |
|
Strength on main deck |
1,6 t/m² |
|
Strength on tank top |
12 t/m² |
|
Tank capacities |
Water ballast: 1.144,60 m³ Bunker: 126 t Gas oil: 135,74 m³ |
|
Anchor equipment |
3 Anchors weight each 1.440 kg Chain length: 412,50 m |
|
Manager |
Boeckmans België NV |
|
Owner |
Rederij AD & C NV |
|
Special annotation |
Wheelhouse hydraulic lowering Vessel is fitted with two moveable bulkheads, not fully box-shaped |
|
Latest data adjustment |
17 October 2018 |
