Antwerpen 16 August 2017 |
 |
 |
|
| Antwerpen 13/08/17 | Antwerpen 07/08/17 |
|
Name |
IMPALA |
|
Type |
Multi-purpose dry cargo ship - Strengthened for heavy cargo - boxshaped/open hatch |
|
IMO-number |
9370111 |
|
Call sign |
V2DG4 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
9.556 t |
|
DWT |
Summer: 13.425,3 t |
|
NT |
4.378 t |
|
Number of 20ft containers |
1.850 |
|
Container capacity 14t |
1.300 |
|
Reefer capacity |
300 |
|
Length |
138,09 m overall 130,00 m between perpendiculars |
|
Breadth |
21,24 m extreme 21,00 m moulded |
|
Draught |
8,00 m |
|
Depth |
11,00 m |
|
Speed |
Max.: 14,7 knots Service: 12,0 knots |
|
Built |
2008 |
|
Keel laid |
27.11.2007 |
|
Launch date |
09.02.2008 |
|
Date of completion |
20.05.2008 |
|
Builder |
Jiangsu Yangzijiang Shipbuilding Co., Ltd. |
|
Yard number |
YZJ2005-695C |
|
Hull material |
Steel |
|
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
|
Bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W 7S35MC - 2 stroke7 cylinder 350 x 1.400 mm diesel engine 5.180 kW at 173 rpm Transmission: Main propulsion acts directly on the propellershaft Starter type: Compressed air direct Builder: MAN B&W Diesel A/S Frederikshavn diesel engine - Denmark |
|
Propellers |
1x Controllable pitch propeller - aft at 173,0 rpm |
|
Boilers |
1x Auxiliary boiler, composite - 9,0 ar Heating surface 26,8 m² Builder: KangRim Industries Co., Ltd. (3rd Factory) |
|
Generators |
3x D2840 LE 301 main diesel generatorsets each 500 kVA |
|
Emergency generator |
1x D0824 LE 201 diesel generatorset 125 kVA |
|
Compressed air receivers |
1x Receiver 50 litres - 33,0 bar |
|
Bow thruster |
1x Model STT 330 TLK - Controllable pitch - 500 kW |
|
Number of holds |
3 |
|
Cargo hold capacity |
16.380 m³ / 578,500 ft³ |
|
Number of hatches |
3 |
|
Max. permitted loads |
Holds: 15,0 t/m² Hatch cover: 1,75 t/m² |
|
Tank capacities |
Ballast: 4.394,2 m³ |
|
Anchor equipment |
3x Anchors weight each 4.320 kg Length: 543,60 m Diameter: 50 mm |
|
Cargo gear |
2x Cranes - SWL 35,0 t each |
|
Manager |
Peter Döhle Schiffahrts-KG |
|
Previous manager |
Bremer Bereederungsgesellschaft mbH & Co. KG Martinistr. 61 |
|
Registered owner |
MS "MYRRHO" Schiffahrtsgesellschaft mbH & Co., KG |
|
Latest data adjustment |
09 March 2018 |
