Westerschelde 06 July 2012 |
 |
 |
 |
||
| Westerschelde 06/07/12 | Antwerpen 24/04/15 | Westerschelde 20/09/18 |
|
Name |
FEDERAL SETO |
|
Type |
Bulk carrier |
|
IMO-number |
9267209 |
|
Call sign |
V7RG6 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flag |
2004 - 2016 Hong Kong - China - Call sign: VRZT5 |
|
GT |
20.661 t registered |
|
DWT |
Summer: 36.489 t Winter: 35.517 t |
|
NT |
12.020 t registered Panama: 17.263 t Suez: 18.942 t |
|
Length |
199,99 m overall 191,00 m between perpendiculars |
|
Breadth |
23,76 m |
|
Draught |
10,73 m |
|
Depth |
14,85 m |
|
Speed |
14,0 knots |
|
Built |
2004 |
|
Keel laid |
16/05/2002 |
|
Launch date |
12/02/2004 |
|
Date of completion |
24/03/2004 |
|
Builder |
Oshima Shipbuilding Co., Ltd. 1605-1 Oshima-cho 857-2494 Saikai City Japan |
|
Yard number |
10346 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 8 |
|
Main engine |
1x Kawasaki/MAN-B&W 6S46MC-C - 2 stroke 6 cylinder diesel engine 7.878 kW / 10.710 hp at 129 rpm Builder: Kawasaki Heavy Industries |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary boiler, composite GCS-22ST Builder: Aalborg Industries A/S |
|
Generators |
3x Daihatsu 6DK-20 diesel generatorsets 740 kW each |
|
Emergency generator |
1x Deutz BF6L913 diesel generatorset |
|
Bow thruster |
1 |
|
Number of holds |
6 Hold 1: 26,08 x 8,20 - 19,86 m Hold 2: 26,98 x 19,86 m Hold 3: 25,18 x 19,86 m Hold 4: 21,58 x 19,86 m Hold 5: 26,08 x 19,86 m Hold 6: 26,06 x 19,86 - 9,80 m |
|
Cargo hold capacity |
Grain / Bale Hold 1: 7.109 m³ / 6.866 m³ Hold 2: 7.990 m³ / 7.663 m³ Hold 3: 7.499 m³ / 7.166 m³ Hold 4: 6.394 m³ / 6.089 m³ Hold 5: 7.759 m² / 7.412 m³ Hold 6: 7.333 m³ / 7.093 m³ Total: 44.054 m³ / 42.289 m³ |
|
Number of hatches |
6 Hatch 1: 17,10 x 13,20 m Hatch 2: 19,80 x 13,20 m Hatch 3: 19,80 x 13,20 m Hatch 4: 13,50 x 13,20 m Hatch 5: 19,80 x 13,20 m Hatch 6: 18,00 x 13,20 m |
|
Hatch covers |
Steel folding hydraulic type |
|
Tank capacities |
IFO: 1.401 m³ MDO: 436 m³ Ballast capacity: 19.730,5 m³ |
|
Anchor equipment |
Length: 605,00 m Diameter: 62 mm |
|
Cargo gear |
3x Electro hydraulic cranes - SWL 30,5 t each |
|
Manager |
Anglo Eastern Shipmanagement Ltd. 23/F, 248 Queen’s Road East, Wanchai Hong Kong |
|
Operator |
Fednav Group 1000 de La Gauchetière Street West Suite 3500 Montreal, QC H3B 4W5 Canada |
|
Owner |
MV Baffin Investments Ltd. C/0 Fednav Ltd. 1000 de La Gauchetière Street West Suite 3500 Montreal, QC H3B 4W5 Canada |
|
Previous owners |
2004 - 2011 Salter Shipping, S.A. |
|
Latest data adjustment |
26 November 2020 |
