| Westerschelde 30 November 2013 |
 |
 |
|
| Antwerpen 15/07/14 | Antwerpen 15/07/15 |
|
Name |
MAGELLAN STRAIT |
|
Previous names |
2001 Start built as: Rio Alexander 11.2003 - 10.2011 Carmel Ecofresh 10.2011 - 05.2013 Cala Paradiso |
|
Type |
Refrigerated cargo ship |
|
IMO-number |
9267534 |
|
Call sign |
PJOT |
|
Flag |
The Netherlands Antilles - Curaçao |
|
Port of registry |
Willemstad |
|
Previous flags |
11.2003 - 12.2005 Liberia, Monrovia 12.2005 - 10.2011 Bermuda, Hamilton - Call sign: ZCDQ4 |
|
GT |
18.931 |
|
DWT |
Summer: 16.478 t |
|
NT |
8.827 t |
|
Container capacity |
270 FEU+74 TEU OR 630 TEU |
|
Reefer plugs |
192 |
|
Length |
185,91 m overall 176,33 m between perpendiculars |
|
Breadth |
25,14 m |
|
Draught |
9,28 m |
|
Freeboard |
3.799 mm |
|
Depth |
13,40 m |
|
Speed |
21,0 knots |
|
Built |
2003 |
|
Keel laid |
05.09.2001 |
|
Launch date |
04.02.2003 |
|
Date of completion |
26.11.2003 |
|
Builder |
ENVC - Estaleiros Navais De Viana Do Castelo, S.A. |
|
Yard number |
213 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Watertight bulkheads |
1 |
|
Main engine |
1x Wärtsilä-Sulzer 7RT-Flex60C - 2 stroke single acting 7 cylinder 600 x 2.250 mm diesel engine - 16.520 kW / 22.446 hp at 114,0 rpm Built: 2002 Builder: Wärtsilä Italiana SpA, Venice - Italy |
|
Propellers |
1x Screw propeller solid - at 114 rpm |
|
Boilers |
1x CHR 185,24 m² - 8,0 bar |
|
Generators |
2x Diesel generatorsets each 1.200 kVA - 960 kW - 1.386 hp |
|
Emergency generator |
1x Diesel generatorset 188 kVA - 150 kW - 272 hp |
|
Number of hold |
3 |
|
Number of compartments |
18 |
|
Cargo capacity |
460.498 ft³ |
|
Floorspace |
5.204,4 m² |
|
Cooling sections |
18 |
|
Tank capacities |
Fuel oil: 1.650,69 m³ |
|
Lifting equipment |
1x Sideloader - SWL 10,4 t |
|
Manager |
Seatrade Shipmanagement 9728 JS Groningen The Netherlands |
|
Previous managers |
11.2003 - 12.2005 Columbus Shipmanagement G.m.b.H., Hamburg - Germany 12.2005 - 05.2013 XT Management Ltd., Haifa - Israel |
|
Operator |
Seatrade |
|
Owner |
Seatrade Management |
|
Previous names & owners |
2001 Rio Alexander - MPC Münchmeyer Petersen Marine G.m.b.H. & Co. K.G. 11.2003 - 12.2005 Carmel Ecofresh - Horizont Schiffahrts G.m.b.H. & Co. K.G., Hamburg - Germany 12.2005 - 20.2011 Carmel Ecofresh - Valshic Shipping Ltd., Haifa - Israel 10.2011 - 05.2013 Cala Paradiso - Valshic Shipping Ltd., Haifa - Israel |
|
Registered owner |
Magellan Strait Shipping Company N.V. |
|
Demolished |
08.2007 at Alang - India |
|
Latest data adjustment |
11 November 2017 |
