| Westerschelde 03 Septemeber 2016 |
|
Name |
LUCKY SUNDAY |
|
Type |
Panamax bulk carrier |
|
IMO-number |
9404338 |
|
Call sign |
H9XL |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
43.717 t Suez: 45.849 t |
|
DWT |
80.372 t |
|
NT |
26.526 t Suez: 41.765,91 t Panama: 36.416 t |
|
Light ships |
12.916 t |
|
Length |
229,04 m overall 221,99 m between perpendiculars |
|
Breadth |
32,31 m extreme 32,27 m moulded |
|
Draught |
Summer: 14,62 m Winter: 14,30 m |
|
Keel to mast top |
Abt 50,00 m |
|
Depth |
20,26 m moulded |
|
Speed |
Max: 15,9 knots Economic: Laden: 12,0 knots In ballast: 13,0 knots |
|
Built |
2009 |
|
Keel laid |
03/11/2007 |
|
Launch date |
01/08/2008 |
|
Date of completion |
04/05/2009 |
|
Builder |
Jiangsu Eastern Heavy Industry Co., Ltd. Jingjiang China |
|
Yard number |
JES05C-063 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 7RT-Flex50-B - 7 cylinder combustion engine Mcr 11.620 kW at 124 rpm |
|
Propellers |
1x Fixed Pitch propeller - 4 blades |
|
Boilers |
1x Auxiliary boiler, composite |
|
Generators |
3x MAN-B&W6 L23/30H main diesel generatorsets each 700 kW / 440 Volt 60 Hz |
|
Emergency generator |
1x MAN-B&W D2866E diesel generatorset |
|
Number of holds |
7 Hold 1: 23,49 x 28,86 m Hold 2: 28,71 x 29,86 m Hold 3: 26,10 x 29,86 m Hold 4: 26,10 x 29,86 m Hold 5: 26,10 x 29,86 m Hold 6: 28,71 x 29,86 m Hold 7: 25,23 x 29,86 m |
|
Cargo hold capacity |
Hold 1: 9.919 m³ Hold 2: 15.168 m³ Hold 3: 13.820 m³ Hold 4: 13.828 m³ Hold 5: 13.839 m³ Hold 6: 15.178 m³ Hold 7: 12.260 m³ Total: 93.800 m³ |
|
Number of hatches |
7 Hatch 1: 13,05 x 13,20 m Hatch 2: 18,27 x 15,00 m Hatch 3: 18,27 x 15,00 m Hatch 4: 18,27 x 15,00 m Hatch 5: 18,27 x 15,00 m Hatch 6: 18,27 x 15,00 m Hatch 7: 15,66 x 15,00 m |
|
Max permitted loads |
On hatches: 1,75 t/m² Tanktop: Hold 1: 30,53 t/m² Hold 2: 20,95 t/m² Hold 3: 30,53 t/m² Hold 4: 21,47 t/m² Hold 5: 30,53 t/m² Hold 6: 20,95 t/m² Hold 7: 30,53 t/m² |
|
Number of pumps |
2x Ballast pumps each 1.650 m³/h |
|
Tank capacities |
Ballast: 33.700,3 m³ (100%) HSFO: 2.357 m³ (98%) LSGO: 464 m³ (98%) MDO: 123 m³ (98%) Bilge tank: 31 m³ (100%) Fresh water: 400 m³ Sewage tank: 42,4 m³ |
|
Anchor equipment |
Length: 687,50 m Diameter: 81 mm |
|
Lifting equipment |
1x Provision crane - SWL 4,0 t |
|
Crew |
25 |
|
Manager |
Klip Marine Shipmanagement OÜ Purje tanav 8/2 11911 Tallinn Estonia |
|
Registered owner |
Lucky Sunday Maritime Ltd. Marshall Islands |
|
Latest data adjustment |
01 March 2024 |
