| Spijkenisse, Ten Netherlands 16 Decemverv 2021 |
|
Name |
VULLY |
|
Type |
Geared self-trimming single deck bulk carrier with accommodation aft - Carriage of dangerous goods |
|
IMO-number |
9583691 |
|
Call sign |
HBDY |
|
Flag |
Switzerland |
|
Port of registry |
Basel |
|
GT |
22.697 t Suez: 23.3232,17 t |
|
DWT |
Summer: 35.717 t Winter: 34.695 t |
|
NT |
12.325 t Suez: 19.980,52 t Panama: 34.240 t |
|
Lightweight |
8.639 t |
|
Displacement |
44.335,5 t |
|
Length |
181,10 m overall 172,00 m between perpendiculars |
|
Breadth |
30,00 m moulded |
|
Draught |
Summer: 10,12 m Winter: 9,91 m |
|
Freeboard |
4.519 mm |
|
Depth |
14,60 m moulded |
|
Speed |
12,0 knots laden |
|
Built |
2011 |
|
Keel laid |
29/11/2010 |
|
Launch date |
21/03/2011 |
|
Delivery date |
22/06/2011 |
|
Builder |
Shinan Heavy Industries Co Ltd. San558, Gamjeong-Ri, Jido-Eup Sinan-Gun Jeollannam-Do 535-801 South Korea |
|
Yard number |
H1008 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W6S50MC6 - 6 cylinder 500 x 1.910 mm combustion engine 8.580 kW / 11.658 bhp at 127,0 rpm Manufacturer: Hyundai Heavy Industries Co, Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Composite Boiler |
|
Generators |
3x Main diesel generatorsets each 600 kW |
|
Emergency generator |
1x Diesel generatorset 120 kW |
|
Number of holds |
5 |
|
Cargo hold capacity |
Grain / bale Hold 1: 8.245 m³ / 7.764 m³ Hold 2: 9.919 m³ / 9.265 m³ Hold 3: 9.835 m³ / 9.249 m³ Hold 4: 9.835 m³ / 9.267 m³ Hold 5: 9.835 m³ / 8.889 m³ Total: 47.669 m³ / 44.434 m³ |
|
Number of hatches |
5 Hatch 1: 16,80 x 15,00 m Hatch 2,3,4,5: 19,20 x 19,20 m |
|
Hatch type |
Seohae end folding type with hydraulic cylinders |
|
Max permitted loads |
Tanktop: 21,0 t/m² |
|
Tank capacities |
Lub oil: 115,50 m³ Fuel oil: 1.538,20 m³ Diesel oil: 152,90 m³ Fresh water: 320,90 m³ Ballast: 19.995,9 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 2,0 t 1x Provision combined crane - SWL 3,0 t 1x Provision handling crane - SWL 3,0 t |
|
Cargo gear |
4x Deck cranes - SWL 30,0 t each |
|
Crew |
21 |
|
Manager |
Suisse-Atlantique Societe de Navigation Maritime SA Avenue des Baumettes 7 1020 Renens 1 Switzerland |
|
Registered owner |
Oceana Shipping AG c/o Suisse-Atlantique, Société de Navigation Maritime S.A. |
|
Latest data adjustment |
17 March 2022 |
