Westerschelde 21 June 2020 |
|
Name |
SHANDONG HONG TU |
|
Previous names |
01/2012 - 11/2014 Xiao Yu |
|
Type |
Bulk carrier - Strengthened for the carriage of heavy cargoes |
|
IMO-number |
9592044 |
|
Call sign |
VRJN2 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
41.206 t Suez: 43.012,57 t |
|
DWT |
Sumer: 76.116 t |
|
NT |
25.658 t Suez: 38.767,76 t Panama: 34.178 t |
|
Displacement |
88.998 t |
|
Length |
225,00 m overall 217,00 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 12,50 m |
|
Forecastle |
14,25 m |
|
Deckhouse |
11,20 m |
|
Freeboard |
5.469 mm |
|
Depth |
19,70 m moulded |
|
Speed |
14,5 knots |
|
Built |
2012 |
|
Keel laid |
13/07/2011 |
|
Launch date |
26/09/2011 |
|
Delivery date |
11/01/2012 |
|
Builder |
Hudong-Zhonghua Shipbuilding (Group) Co., Ltd. 2851 Pu Dong Da Dao Shanghai China |
|
Yard number |
H1642A |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
9 |
|
Continuous decks |
1 Upper deck |
|
Main engine |
1x Hudong/MAN-B&W 5S60MCC - 5 cylinder 600 x 2.400 mm combustion engine 10.000 kW at 101,0 rpm Manufacturer: Hudong Heavy Machinery Co. |
|
Propellers |
1 |
|
Boilers |
1x Fired exhaust gas boiler - 9,0 MPa Manufacturer: Alfa laval Qingdao Ltd. - China |
|
Generators |
3x Main diesel generatorsets each 570 kW Manufacturer: Taiyo Electric Co., Ltd. |
|
Emergency generator |
1x Cummins 6BT5.9-D(M) diesel generatorset |
|
Number of holds |
7 |
|
Cargo hold capacity |
Grain: Hold 1: 11.410,94 m³ Hold 2: 13.501,46 m³ Hold 3: 13.698,71 m³ Hold 4: 12.836,19 m³ Hold 5: 13.764,15 m³ Hold 6: 13.300,46 m³ Hold 7: 12.028,17 m³ Total: 90.540,08 m³ |
|
Number of hatches |
7 1x 14,62 x 13,20 m 6x 14,62 x 15,00 m |
|
Hatch type |
Side rolling |
|
Tank capacities |
Ballast: 35.007,16 m³ Fresh water: 516,72 m³ Diesel oil: 266,52 m³ Fuel oil: 2.709,9 m³ Lub oil: 115,78 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 4,0 t 1x Provision crane - SWL 4,0 t Manufacturer: Ningbo Kairong Ship Machinery Co., Ltd. |
|
Cargo gear |
Gearless |
|
Crew |
28 |
|
Manager |
SDSC - Shandong Shipping Corporation 66 lianyungang road CDB Qingdao China |
|
Registered owner |
Bund 6 Holding Limited |
|
Previous names & owners |
01/2012 - 11/2014 Xiao Yu - Xiaoyu Marine Co Ltd. |
|
Latest data adjustment |
18 November 2020 |
