Name |
MSC SHANNON |
|
Previous names |
1991 - 07/2004 Berlin Senator |
|
Type |
Cellular containership |
|
IMO-number |
8913423 |
|
Call sign |
HPRY |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
37.071 t |
|
DWT |
Summer: 46.600 t |
|
NT |
15.889 t |
|
Number of 20ft containers |
In hold: 1.334 On deck: 4.671 Total: 3.005 |
|
Container capacity 14t |
2.480 |
|
Reefer capacity |
100 |
|
Length |
237,00 m overall 225,25 m between perpendiculars |
|
Breadth |
32,20 m extreme |
|
Draught |
11,98 m |
|
Depth |
18,80 m |
|
Speed |
Max.: 21,0 knots |
|
Built |
1991 |
|
Keel laid |
16/11/1990 |
|
Launch date |
22/06/1991 |
|
Date of completion |
15/11/1991 |
|
Builder |
Bremer Vulkan AG Schiffbau und Maschinenfabrik Bremen Germany |
|
Yard number |
91 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 7L80MC - 2 stroke single acting 7 cylinder 800 x 2.592 mm combustion engine Mcr 21.700 kW / 29.503 hp at 88,0 rpm Year of manufacture: 1992 Manufacturer: Bremer Vulkan AG Schiffbau und Maschinenfabrik Lindenstr. 110 28755 Bremen Federal Republic of Germany |
|
Propellers |
1x Fixed pitch propeller - aft at 88,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 54,0 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 320,0 m² |
|
Shaft generator |
1x 1.200 kW / 1.500 kVA - 220/240 Volt 60 Hz |
|
Generators |
3x MAN-B&W 6L23/30MDB main diesel generatorsets each 1.138 kVA / 910 kW - 220/240 Volt 60 Hz |
|
Emergency generator |
1x Caterpillar 3306 DIT diesel generatorset 180 kVA |
|
Compressed air receivers |
1x Receiver 250 litres - 40,0 bar 2x Receivers each12.000 litres - 31,0 bar 1x Receiver 40 litres - 30,0 bar |
|
Bow thruster |
1x Controllabe pitch propeller LIPS - 1.300 kW / 1.767 bhp, forward |
|
Tank capacities |
Ballast: 19.198,2 m³ Fuel oil: 2.661 m³ Diesel oil: 189 m³ |
|
Number of holds |
7 |
|
Anchor equipment |
3x Anchors weight each 11.100 kg Length: 880,00 m Diameter: 81 mm |
|
Cargo gear |
Gearless |
|
Crew size |
23 |
|
Commerical manager |
MSC Mediterranean Shipping Co. chemin Rieu, 12-14 1208 Geneva Switzerland |
|
ISM manager |
MSC Shipmanagement Limited MSC House, 8, Spyrou Kyprianou Avenue Limassol Cyprus |
|
Previous managers |
Unicom Management Services (Cyprus) Ltd. |
|
Registered owner |
Compania Naviera Shannon S.A. - Republic of Panama Care of MSC Mediterranean Shipping Co., SA chemin Rieu 12-14 1208 Geneva Switzerland |
|
Previous owners |
Megaslot III Shipping Co. Ltd. |
|
Renamed |
05/2023 MSC Shannon III Republic of Panama, Panama City - Call sign: HPRY Owner: Compania Naviera Shannon S.A Manager: MSC Shipmanagement Limited |
|
Latest data adjustment |
20 May 2022 |
