Mogens Maersk - IMO 9632090

Name

MOGENS MAERSK (MOGENS MÆRSK)

Type

Cellular containership - Carriage of dangerous goods

IMO-number

9632090

Call sign

OWSC2

Flag

Denmark

Port of registry

Hellerup

GT

194.849 t

Suez: 199.185,85 t

DWT

194.679 t

NT

89.317 t

Suez: 174.365,66 t

Displacement

257.997,2 t

Number of 20ft containers

In hold: 7.600

On deck: 10.740

Total: 18.340

Container capacity 14t

10.562

Reefer capacity

600

Length

399,00 m overall

376,21 m between perpendiculars

Breadth

59,00 m moulded

Draught

16,00 m

Freeboard

6.845 mm

Depth

30,30 m moulded

Speed

Max: 23,0 knots

Service: 19,0 knots

Built

2014

Keel laid

27/02/2014

Launch date

31/05/2014

Delivery date

17/09/2014

Builder

Daewoo Shipbuilding & Marine Engineering Co., Ltd.

3370 Geoje-Daero, Geoje-Si, 53302

South Korea

Yard number

4263

Hull material

Steel

Continuous decks

1

Main engine

2x MAN-B&W 7S80ME-C9 - 2 stroke single acting 7 cylinder 800 x 3.450 mm combustion engine each Mcr 29.300 kW / 39.836 hp at 77,7 rpm

Builder: Doosan Engine Co., Ltd. - South Korea

Propellers

2x Fixed pitch propellers- aft at 72,0 rpm

Manufacturer: Mecklenburger Metallguss GmbH

Boilers

• 1x Auxiliary boiler Aalborg OS - 9,0 MPa

• 2x Exhaust gas economizer Aalborg XS-TC7A - 12,5 MPa

• 2x H.P. exhaust gas economizer Aalborg (Mission) XW-TG (HP) - 14,0 MPa

• 2x L.P. Exhaust Gas Economizer Aalborg (Mission) XW-TG (LP) - 8,0 MPa

Manufacturer: Alfa Laval Qingdao Ltd.

Shaft generator

2x Generators 3.000 kW each

Manufacturer: Siemens AG I AC 222

Auxiliary generators

1x MAN-B&W 9L32/40 diesel generatorset 4.300 kW

2x MAN-B&W 6L32/40 diesel generatorsets 2.800 kW each

1x Turbo/Generator 6.000 kW

Manufacturer: HHI Electro Electric System

Bow thruster

2x Tunnel thruster each 2.500kW / 3.399 bhp, forward

Cargo hold capacity

384.683,60 m³

Tank capacities

Lub oil: 588,60 m³

Diesel oil: 1.100,80 m³

Fuel oil: 10.018,60 m³

Fresh water: 1.048,30 m³

Ballast: 63.173,20 m³

Lifting equipment

2x Engine room cranes Port & Stbd - SWL 10,0 t each

1x Monorail crane - SWL 12,5 t

1x Provision crane Port - SWL 2,0 t

1x Provision crane Stbd - SWL 5,0 t

Manufacturer: Dongnam Marine Crane Co., Ltd.

Crew size

22

ISM & commercial manager

Maersk Line A/S

Esplanaden 50

1098 Copenhagen, K

Denmark

Registered owner

Maersk Line A/S

Esplanaden 50

1098 Copenhagen, K

Denmark

Latest data adjustment

21 August 2023
