Malaga, Spain 09 September 2021 |
|
Name |
SAG GOOD TIMING |
|
Previous names |
Vega Mercury |
|
Type |
Cellular containership |
|
IMO-number |
9403463 |
|
Call sign |
V7A4896 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
Liberia, Monrovia - Call sign: A8PT9 |
|
GT |
9.957 t |
|
DWT |
Summer: 13.702 t |
|
NT |
5.020 t |
|
Number of 20ft containers |
In hold: 334 On deck: 784 Total: 1.118 |
|
Number of 40ft containers |
In hold: 162 + 20 TEU On deck: 380 + 22 TEU Total: 542 + 32 TEU |
|
Container capacity 14t |
696 |
|
Reefer capacity |
220 |
|
Length |
147,80 m 140,30 m between perpendiculars |
|
Breadth |
23,28 m |
|
Draught |
Summer: 8,20 m |
|
Keel to mast end |
45,20 m |
|
Depth |
11,40 m |
|
Speed |
Max: 19,6 knots |
|
Built |
2009 |
|
Keel laid |
04/08/2008 |
|
Delivery date |
10/03/2009 |
|
Builder |
Taizhou Kouan Shipbuilding Co., Ltd. Taizhou Jiangsu China |
|
Yard number |
KA412 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 7L58/64CD - 4 stroke 7 cylinder 580 x 640 mm combustion engine Mcr 9.732 kW at 428 rpm |
|
Propellers |
1x Controllable pitch propeller - aft at 131,0 rpm 4 bladed |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 38,0 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 115,0 m² Builder: GESAB Hoch-Temperatur Industrieanlagen GmbH |
|
Shaft generator |
1x 1.750 kVA |
|
Generators |
3x MAN-B&W 6L16/24 main diesel generatorsets each 712,5 kVA |
|
Emergency generator |
1x Diesel generatorset 687,5 kVA |
|
Batteries |
1x Battery for automation 200 Ah |
|
Compressed air receivers |
2x Receivers each 1.250 litres - 30,0 bar 1x Receiver 30 litres - 30,0 bar |
|
Bow thruster |
1x Jastram transverse thruster 750 kW |
|
Number of holds |
5 No.1 dim. 14,00 x 10.40 x 11,18 m No.2 dim. 12,60 x 18,00 x 11,18 m No.3A dim. 12,60 x 18,00 x 11,18 m No.3B dim. 12,60 x 18,00 x 11,18 m No.4A dim. 12,60 x 18,00 x 11,18 m No.4B dim. 12,60 x 18,00 x 11,18 m No.5 dim. 12,60 x 18,00 x 11,18 m |
|
Tank capacities |
Heavy fuel oil: 1.368,8 m³ Marine diesel oil: 225;6 m³ Lub oil: 52;2 m³ Ballast water: 5.198;81 m³ Fresh water: 166,4 m³ |
|
Anchor equipment |
3x Anchors weight each: 6.000 kg Length: 577,50 m |
|
Cargo gear |
2x Liebherr cranes - SWL 45,0 t each |
|
Crew size |
22 |
|
ISM & commercial manager |
Vega-Reederei GmbH & Co KG Paul-Dessau-Strasse 3A 22761 Hamburg Germany |
|
Registered owner |
CO 12 Schiffahrts KG Care of Vega-Reederei GmbH & Co KG Paul-Dessau-Strasse 3A 22761 Hamburg Germany |
|
Latest data adjustment |
28 September 2021 |
