Malaga, Spain 26 January 2021 |
|
Name |
MSC TERESA |
|
Type |
Cellular containership |
|
IMO-number |
9469560 |
|
Call sign |
3FZP9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
153.115 t |
|
DWT |
Summer: 166.101,4 t |
|
NT |
89.067 t |
|
Number of 20ft containers |
14.000 |
|
Container capacity 14t |
10.640 |
|
Reefer capacity |
2.000 |
|
Length |
365,80 m overall 349,51 m between perpendiculars |
|
Breadth |
51,30 m extreme 51,20 m moulded |
|
Draught |
Summer: 16,00 m |
|
Depth |
29,90 m |
|
Speed |
Max: 24,1 knots |
|
Built |
2011 |
|
Keel laid |
12/10/2010 |
|
Launch date |
27/11/2010 |
|
Date of completion |
10/03/2011 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Okpo Shipyard Geoje-si South Korea |
|
Yard number |
4195 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x Doosan/MAN-B&W 12K98MC-C - 12 cylinder 980 x 2.400 mm combustion engine 72.240 kW at 104,0 rpm Build: 2010 Manufacturer: Doosan Engine Co., Ltd.- South Korea |
|
Propellers |
1x Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired MISSION TM OS - 10,0 bar Heating surface: 46,2 m² 1x Steam boiler, exhaust gas heated MISSION XS2V- 10,0 bar Heating surface: 679,0 m² Build: 2010Manufacturer Manufacturer: Alfa Laval Aalborg A/S |
|
Electric installations |
1x Plant 6.600 V - 5.120 kVA 1x Plant 6.600 V - 5.120 kVA 1x Plant 6.600 V - 5.120 kVA 1x Plant 6.600 V - 5.120 kVA 1x Plant 450 V - 688 kVA 1x Plant 24 V - 15 Ah 1x Plant 24 V - 63 Ah 1x Plant 24 V - 92 Ah 1x Plant 24 V - 300 Ah 1x Plant 24 V - 300 Ah 2x Plants each 108 V - 40 Ah |
|
Generators |
4x MAN 8L32/40 main diesel generatorsets each 4.096 kW / 5.120 kVA |
|
Emergency generator |
1x Cummins VTA28DM diesel generatorset 688 kVA |
|
Batteries |
1x Battery for UPS navigation 300 Ah 1x Battery for UPS radio 300 Ah 1x Battery for automation 92 Ah 1x Battery for diesel control 63 Ah 2x Batteries for automation, each 40 Ah 1x Battery for diesel control 15 Ah |
|
Compressed air receivers |
2x Receivers, each 16.500 litres - 30,0 bar 1x Receiver 540 litres - 30,0 bar 1x Receiver 200 litres - 30,0 bar 1x Receiver 2000 litres - 7,0 bar 1x Receiver 350 litres - 7,0 bar |
|
Bow thruster |
2x Transverse thruster each 1.800 kW, forward |
|
Tank capacities |
Ballast: 47.621,4 m³ |
|
Anchor equipment |
3x Anchors weight each 26.000 kg Length: 782,00 m Diameter: 127 mm |
|
Cargo gear |
Gearless |
|
Crew size |
30 |
|
Manager |
Mediterranean Shipping Company S.r.l. Via Francesco Ciampa 29 80063 Piano di Sorrento Napoli Italy |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Registered owner |
Akela Shipping Inc. Care of MSC Mediterranean Shipping Company Co. SA Chemin Tieu 12-14 1208 Geneva Switzerland |
|
Latest data adjustment |
01 February 2021 |
