Molde, Norway 30 May 2019 |
 |
| Molde, Norway 30/05/19 |
|
Name |
MOLDEFJORD |
|
Type |
Roll-On/Roll-Off carrier - Ferry |
|
IMO-number |
9477115 |
|
Call sign |
LCBA |
|
Flag |
Norway |
|
Port of registry |
Molde |
|
GT |
2.971 t |
|
DWT |
857 t |
|
NT |
892 t |
|
Length |
122,68 m overall 116,27 m between perpendiculars |
|
Breadth |
16,19 m |
|
Draught |
Max: 3,50 m |
|
Depth |
5,01 m |
|
Speed |
Service: 11,0 knots Max: 15,4 knots |
|
Route |
Molde - Vestnes |
|
Built |
2009 |
|
Keel laid |
18/07/2008 |
|
Launch date |
27/02/2009 |
|
Date of completion |
20/11/2009 |
|
Builder casco |
Stocznia Polnocna S.A. (Northern Shipyard) Poland |
|
Builder completion |
Gdanska Stocznia 'Remontowa' S.A. Yard number: 1994/1 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
2x Mitsubishi GS16R-MPTK - LNG powered s combustion engines each 1.000 kW Total: 2.000 kW / 2.719 bhp |
|
Propellers |
2x Azimuth thrusters each 1.000 kW (fore and aft) |
|
Generators |
2x LNG combustion generatorsets each 840 kW 1x Diesel combustion Mitsubishi S12R-MPTK generatorset 900 kW (Back up engine) |
|
Number of passengers |
390 |
|
Number of cars |
125 |
|
Cars/trailers combination |
12 trailers + 55 cars |
|
Deck load total |
750 t |
|
Deck machinery / equipment |
2x Capstans hydraulically operated: 3 tons pull Main Evacuation System: |
|
Tank capacities |
LNG: 125 m³ Fuel oil: 22 m³ Fresh water: 27 m³ |
|
Crew size |
9 |
|
Manager |
Fjord1 Nordvestlandske AS |
|
Operator |
Fjord1 Nordvestlandske AS |
|
Previous operator |
2009 - 10/2002 Fjord1 MRF AS, Molde - Norway |
|
Registered owner |
Fjord1 Nordvestlandske ASA |
|
Latest data adjustment |
07 August 2019 |
