Name
|
MORNING COMPOSER
|
|
Type
|
Roll-On/Roll-Off car carrier
PCTC - Pure Car and Truck carrier
|
|
IMO-number
|
9336074
|
|
Call sign
|
3FAT4
|
|
Flag
|
Republic of panama
|
|
Port of registry
|
Panama City
|
|
GT
|
57.542 t
|
|
DWT
|
Summer: 21.052 t
|
|
NT
|
20.901 t
|
|
Length
|
199,97 m
|
|
Breadth
|
32,26 m
|
|
Draft
|
10,01 m
|
|
Reg. dimensions L x Bx D
|
193,13 x 32,26 x20,11 m
|
|
Rule dimensions L x Bx D
|
189,20 x 32,26 x 14,30 m
|
|
Freeboard
|
Summer: 3.534 mm
|
|
Depth
|
20,11 m
|
|
Speed
|
20,5 knots
|
|
Built
|
2008
|
|
Keel laid
|
28.09.2007
|
|
Launch date
|
08.12.2007
|
|
Date of completion
|
24.03.2008
|
|
Builder
|
Hyundai Samho Heavy Industries Co., Ltd.
Mokpo
South Korea
|
|
Yard number
|
S0292
|
|
Hull material
|
Steel
|
|
Watertight bulkheads
|
Transverse: 4
|
|
Number of decks
|
7
|
|
Main engine
|
1x 2 stroke single acting 7 cylinder 600 x 2.292 mm combustion engine 14.280 kW at 105,0 rpm
Built: 09.2007
Manufacturer: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea
|
|
Propellers
|
1x Fixed propeller
|
|
Boilers
|
1x Auxiliary boiler Water tube boiler - 8,8 bar
Heating surface: 24 m²
2x Economizer exhaust gas boiler 12,0 bar
Heating surface: 226,5 m²
Built: 08.2007
Manufacturer: Kang Rim Ind. Co., Ltd., Changwon - South Korea
|
|
Generators
|
3x Main diesel generatorsets each 1.475 kVA / 450 Volt
|
|
Bow thruster
|
1x 1.345 kW
|
|
Number of cars
|
6.645
|
|
Number of trucks
|
412
|
|
Tank capacities
|
Fuel oil: 4.130,6 m³
Fresh water: 323,8 m³
Water ballast: 5.877,1 m³
|
|
Crew
|
22
|
|
Manager
|
Wilhelmsen Ship Management
Pusan,
South Korea
|
|
Technical manager
|
Wilhelmsen Ship Management
|
|
Operator
|
EUKOR car Carriers
Seoul
South Korea
|
|
Registered owner
|
MP - PAN S.A.
|
|
Latest data adjustment
|
15 November 2017
|
