Westerschelde 11 May 2018 |
 |
| Zeebrugge 04/07/17 |
|
Name |
GLOVIS CONDUCTOR |
|
Previous names |
2006 - 10/2012 Favorite Ace |
|
Type |
Roll-On/Roll-Off carrier - Vehicle carrier |
|
IMO-number |
9293909 |
|
Call sign |
3EIC6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
60.118 t registered |
|
DWT |
17.709 t |
|
NT |
18.543 t registered |
|
Length |
199,99 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 9,72 m |
|
Moulded L x B x D |
192,00 x 32,26 x 14,65 m |
|
Registered L x B x D |
193,94 x 32,26 x 21,17 m |
|
Freeboard |
Summer: 4.956 mm |
|
Depth |
14,65 m moulder |
|
Speed |
Service: 20,0 knots Max.: 22,1 knots |
|
Built |
2006 |
|
Keel laid |
09/12/2004 |
|
Launch date |
25/08/2006 |
|
Date of completion |
20/11/2006 |
|
Builder |
Shin Kurushima Dockyard Co., Ltd. Imabari Japan |
|
Yard number |
5308 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsubishi 8UEC60LSII - 2 stroke single acting 8 cylinder 600 x 2.200 mm combustion engine 15.090 kW / 20.236 bhp at 98,0 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 665 mm |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 3,82 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Electric installations |
3x Main diesel generatorsets each 1.100 kW |
|
Number of cars |
5.231 |
|
Tank capacities |
Fuel oil: 2.991 m³ Fresh water: 404 m³ Ballast water: 7.400 m³ |
|
Lifting equipment |
2x Cranes - SWL 4,0 t each |
|
Crew |
20 |
|
Manager |
OSM Ship Management Pte Ltd. |
|
Operator |
Hyundai Glovis Co. Ltd. 301, Teheran-ro, Gangnam-gu Seoul South Korea |
|
Registered owner |
SFL Conductor Inc. |
|
Renamed |
2019 SFL Conductor Laid up from 20/05/2020 |
|
Latest data adjustment |
08 July 2020 |
