| Zeebrugge 20 August 2003 |
|
Name |
PEGASUS LEADER |
|
Type |
Roll-On/Roll-Off vehicles carrier |
|
IMO-number |
9181560 |
|
Call sign |
3FUM9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama |
|
GT |
57.566 t |
|
DWT |
22.747 t |
|
NT |
17.270 t |
|
Length |
199,93 m overall 192,88 m registered |
|
Breadth |
32,26 m over all |
|
Moulded L x B x D |
190,00 x 32,26 x 15,27 m |
|
Registered L x B x D |
192,88 x 32,26 x 23,68 m |
|
Draught |
10,019 m |
|
Freeboard |
Summer: 5.285 mm |
|
Depth |
15,27 m moulded |
|
Speed |
19,3 knots |
|
Built |
1999 |
|
Keel laid |
10.06.1998 |
|
Launch date |
05.08.1999 |
|
Date of completion |
18.11.1999 |
|
Builder |
Shin Kurushima Dockyard Co. Ltd. |
|
Yard number |
5013 |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsubishi 60LS - 2 stroke single acting 8 cylinder 600 x 2.200 mm diesel engine - 14.121 kW at 100,0 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works |
|
Number of screws |
1 |
|
Boiler |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 3,27 t/h Manufacturer: Tortoise Engineering Co. Ltd. |
|
Generators |
4x Main diesel generatorsets each 4.275 kVA |
|
Car capacity |
5.053 |
|
High car cap. height 2,0 m |
4.345 |
|
Ramp loadable tons |
150 |
|
Tank capacities |
Fuel oil: 3.484 m³ Fresh water: 456 m³ Ballast water: 9.302 m³ |
|
Lifting equipment |
2x Cranes - SWL 4,0 t each |
|
Manager |
Wilhelmsen Ship Management SDN BHD |
|
Operator |
NYK-Line – Nippon Yusen Kaisha Line |
|
Registered owner |
Pegasus Maritima Shipholding S.A. Republic of Panama |
