Westerschelde 16 August 2019 |
 |
 |
|
| Westerschelde 16/08/19 | Westerschelde 16/08/19 |
|
Name |
NEPTUNE ACE |
|
Type |
Roll-On/Roll-off carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9584059 |
|
Call sign |
C6YU3 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
59.006 t |
|
DWT |
Summer: 18.436 t |
|
NT |
18.299 t |
|
Length |
199,95 m overall |
|
Breadth |
32,20 m moulded |
|
Draught |
Max: 9,82 m |
|
Moulded L x B x D |
190,00 x 32,20 x 14,70 m |
|
Registered L x B x D |
190,88 x 32,20 x 21,25 m |
|
Freeboard |
Summer: 4.914 mm |
|
Depth |
14,70 m moulded |
|
Speed |
Max: 22,2 knots |
|
Built |
2010 |
|
Keel laid |
08/01/2010 |
|
Launch date |
29/06/2010 |
|
Date of completion |
27/10/2010 |
|
Builder |
Minaminippon Shipbuilding Co., Ltd. Usuki Japan |
|
Yard number |
714 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsui/MAN-B&W 7S60MC-C - 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 15.130 kW at 100,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 620 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 7,8 bar Evaporation: 3,98 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 1.000 kVA |
|
Emergency generator |
1x Diesel generatorset 900 kVA |
|
Bow thruster |
1.510 kW |
|
Number of cars |
5.072 |
|
Ro-Ro ramp |
1x Starboard 1x Starboard aft |
|
Tank capacities |
Fuel oil: 2.861 m³ Fresh water: 331 m³ Ballast: 7.435 t |
|
Crew size |
32 |
|
Manager |
MOL Ship Management (Singapore) Pte. Ltd. |
|
Operator |
MOL Auto Carrier Express - MOL ACE |
|
Registered owner |
Glacier Transport Inc. |
|
Latest data adjustment |
06 August 2020 |
