| Spijkenisse, The Netherlands 21 April 2021 |
|
Name |
MAAS |
|
Type |
Hybrid water injection dredger |
|
IMO-number |
9904948 |
|
Call sign |
PDTY |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
482 t |
|
DWT |
204 t |
|
NT |
144 t |
|
Length |
43,07 m overall 35,79 m between perpendiculars |
|
Breadth |
9,70 m |
|
Draught |
2,10 m |
|
Freeboard |
1.306 mm |
|
Depth |
3,40 m |
|
Speed |
10,2 knots |
|
Built |
2021 |
|
Date of completion |
23/04/2021 |
|
Builder casco |
Shipyard Bomex 4M d.o.o. Zrenjanin Serbia |
|
Builder completion |
Scheepswerf Gebroeders Kooiman B.V. Zwijndrecht The Netherlands |
|
Yard number |
215 |
|
Hull material |
Mild steel |
|
Watertight compartments |
23 |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar C32 Acert - 4 stroke 12 cylinder 145 x 162 mm combustion engines total 1.066 kW / 1.448 hp at 1.800 rpm which is coupled to a hybrid energy management system whereby electricity is generated by heat recovery and stored in batteries |
|
Propelling type |
Electrical |
|
Propellers |
2x Azimuth thruster solid - aft at 1.000 rpm |
|
Generators |
1x Diesel generatorset 100 kVA - 80 kW - 117 hp |
|
Total installed power |
2.044 kW |
|
Bow thruster |
1x Tunnel bow thruster |
|
Dredging depth |
Min: 1,80 m Max: 24,00 m |
|
Tank capacities |
Fuel: 102,0 m³ |
|
Accommodation |
For 6 persons |
|
Owner |
Koninklijke Van Oord NV Schaardijk 211 3063 NH Rotterdam The Netherlands |
|
Latest data adjustment |
12 March 2022 |
