Westerschelde 02 April 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 13/11/17 | Westerschelde 13/11/17 | Westerschelde 08/08/19 | Westerschelde 08/08/19 | Westerschelde 17/09/18 | Westerschelde 30/01/18 | |||||
|
Name |
APL MERLION |
|
Previous names |
2013 Launch as: APL Ambassador |
|
Type |
Cellular containership |
|
IMO-number |
9632014 |
|
Call sign |
S6NV |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
151.015 t Suez: 157.389 t |
|
DWT |
Summer: 150.166 |
|
NT |
63.838 t Suez: 146.564 t |
|
Number of 20ft containers |
13.892 |
|
Container capacity 14t |
9.680 |
|
Reefer capacity |
1.200 |
|
Length |
368,50 m overall 352,00 m between perpendiculars |
|
Breadth |
51,00 m |
|
Draught |
15,52 m |
|
Depth |
29,85 m |
|
Speed |
24,7 knots |
|
Built |
2014 |
|
Keel laid |
03/06/2013 |
|
Launch date |
17/08/2013 |
|
Date of completion |
15/02/2014 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Samho South Korea |
|
Yard number |
S636 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Single side |
|
Main engine |
1x Hyundai/MAN-B&W 11S90ME-C9.2 - 2 stroke 11 cylinder combustion engine 62.030 kW / 84.336 hp at 83,0 rpm kW |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
2x Auxiliary boiler, exhaust gas heated Manufacturer: Kangrim Heavy Industries |
|
Generators |
2x Hyundai/Himsen 8H32/40 main diesel generatorsets each 3.840 kW 2x Hyundai/Himsen 9H32/40 main diesel generatorsets each 4.300 kW Manufacturer: Hyundai Engine & Machinery Co. Ltd. |
|
Emergency generator |
1x Scania DI16 diesel generatorset 846 kW Manufacturer: Scania CV AB, Industrial & Marine Engines |
|
Bow thruster |
2x 1.800 kW |
|
Tank capacities |
Ballast: 42.720,6 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 127 mm |
|
Cargo gear |
Gearless |
|
Commercial manager |
CMA CGM Asia Shipping Pte Ltd. 14-01, The Metropolis, 9, North Buona Vista Drive, Singapore 138588 Republic of Singapore |
|
ISM manager |
CMA CGM International Shipping Company Pte. Ltd. 14-01, The Metropolis (Tower 1), 9, North Buona Vista Drive Singapore 138588 Republic of Singapore |
|
Registered owner |
CMA CGM Asia Pacific Liner Pte. Ltd. Care of Neptune Shipmanagement Services (Pte) Ltd (NSSPL) 14-01, The Metropolis, 9, North Buona Vista Drive, Singapore 138588 Republic of Singapore |
|
Latest data adjustment |
02 April 2024 |
