Westerschelde 21 August 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 21/08/19 | Westerschelde 11/05/18 | Antwerpen 04/11/18 | Westerschelde 23/09/20 | Westerschelde 23/09/20 | Westerschelde 08/10/19 | |||||
 |
||||||||||
| Westerschelde 10/05/20 | ||||||||||
|
Name |
MULTRATUG 29 |
|
Type |
Tug boat - Escort tug - Fire fighting ship |
|
IMO-number |
9795816 |
|
Call sign |
PBVV |
|
Flag |
The Netherlands |
|
Port of registry |
Terneuzen |
|
GT |
450t |
|
DWT |
172 t |
|
NT |
135 t |
|
Length |
32,70 m overall 31,25 m between perpendiculars |
|
Breadth |
12,10 m |
|
Draught |
4,00 m |
|
Freeboard |
724 mm |
|
Depth |
5,35 m |
|
Speed |
Max: 14,0 knots |
|
Built |
2018 |
|
Date of completion |
07/05/2018 |
|
Builder |
Song Cam Shipbuilding Joint Stock Company Vietham |
|
Yard number |
512548 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
3 |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar 3516C HD TA/D - 4 stroke 16 cylinder 170 x 190 combustion engine total 5.05 kW / 6.862 hp at 1.800 rpm Builder: Caterpillar Inc.,Lafayette, IN - USA |
|
Propulsion |
2x Rolls Royce US 255 Controllable pitch azimuth thruster solid - diameter: 2.800 mm |
|
Electric installations |
230/400 Volt - 50 Hz |
|
Generators |
2x Caterpillar C6.6TA main diesel generatorsets each 125 kVA - 100 kW - 148 hp |
|
Deck lay-out |
|
|
Bollard pull |
Max: 82,6 t |
|
FIFI 1 System |
Type: Main engine driven pumps capacity 2x 1.450 m³/h FIFI monitors: 2x 1.200 m³/h - water / foam |
|
Tank Capacities |
Fuel oil: 131,2 m³ Fresh water: 15,2 m³ Lubrication oil: 8,1 m³ Foam: 12,5 m³ Dirty oil: 4,2 m³ Bilgewater: 6,7 m³ Sludge: 2,5 m³ Hydraulic oil: 2,8 m³ Sewage: 8,9 m³ |
|
Accommodation |
1-man cabin: 2 2-men cabin: 4 Messroom: 1 Galley: 1 |
|
Operator |
Multraship Towage & Salvage Schuttershofweg 1 4530 AB Terneuzen The Netherlands |
|
Registered owner |
Multratug 29 B.V. |
|
Latest data adjustment |
10 October 2021 |
