Vlissingen, The Netherlands 31 July 2015 |
 |
 |
 |
 |
 |
||||
| Vlissingen 31/07/15 | Vlissingen 31/07/15 | Antwerpen 16/11/15 | Antwerpen 08/05/16 | Antwerpen 18/08/16 | ||||
|
Name |
MULTRATUG 30 |
|
Type |
Escort tug - Fire fighting |
|
IMO-number |
9695482 |
|
Call sign |
PCZR |
|
Flag |
The Netherlands |
|
Port of registry |
Terneuzen |
|
GT |
553 t |
|
NT |
135 t |
|
Length |
32,70 m overall 28.84 m between perpendiculars |
|
Breadth |
12,82 m overall |
|
Draught |
Max.: 5,50 m |
|
Freeboard |
623 mm |
|
Depth |
5,35 m |
|
Speed |
Max.: 13,4 knots |
|
Built |
2015 |
|
Date of completion |
12.05.2015 |
|
Builder casco |
Song Cam Shipbuilding Joint Stock Company Vietnam Yard number: 512529 |
|
Builder completion |
Damen Shipyard Gorinchem |
|
Hull material |
Steel |
|
Watertight compartments |
3 |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar 3516C HD TA/D - 4 stroke 12 cylinder 170 x 190 mm diesel engines 5.050 kW / 6.772 bhp at 1.800 rpm Built: 11.02.2013 Builder: Caterpillar Inc., Lafayette - USA |
|
Propulsion |
2x Azimutht hrusters Rolls Royce US 255 CP controllable pitch - 2.800 mm diameter at 1.800 rpm |
|
Generators |
2x Caterpillar C6.6TA generatorsets each 125 kVA - 100 kW - 159 hp / 230/400 Volt, 50 Hz |
|
Bollard pull |
82,4 t |
|
Deck lay-out |
Anchor/ towing winch: Hydraulically driven escort winch with double drum Type: DMS T320 –HH 2 –M2 – 22 DAM Capacity: 2x 200,00 m, Ø 60 mm Brake capacity: 200 ton 2nd layer Anchor: 2x 495 kg Chain: 302,5 m Ø 22 mm/ U 2/ Q 2 Towing winch aft: DMS T320 – HHT – ESD Brake capacity: 200 ton 2nd layer Capacity: 750,00 m, Ø 54 mm Towing hook aft: 100 ton Capstan: 5 t |
|
FIFI 1 System |
Main engine driven pumps capacity 2x 1.450 m³/h FIFI Monitors: 2x 1.200 m³/h - water / foam |
|
Tank capacities |
Fuel oil: 131,2 m³ Fresh water: 15,2 m³ Lubrication oil: 8,1 m³ Foam: 12,5 m³ Dirty oil: 4,2 m³ Bilge water: 6,7 m³ Sludge: 2,5 m³ Hydraulic oil: 2,8 m³ Sewage: 8,9 m³ |
|
Lifting equipment |
1x Deck crane - SWL 2.200 kg at 8,60 m |
|
Accommodation |
2x 1-Man cabins 4x 2-Men cabins Mess room Galley |
|
Owner |
Multraship Towage & Salvage Scheldekade 48 |
|
Registered owner |
Global Ship Leasing 30 B.V. |
|
Renamed |
2018 Shalder United Kingdom - Call sign: MCQC3 |
|
Latest data adjustment |
08 September 2015 |
