DMS Globe 01
Spijkenisse 06 June 2009



Name

DMS GLOBE

Type

Tug - DAMEN Shoalbuster 2609

Basic functions

Towing, mooring, anchor handling, dredging support

IMO-number

9304904

Call sign

PFCQ

Flag

The Netherlands

Port of registry

Hardinxveld

GT

212 t

NT

61 t

Length

26,02 m overall

24,00 m between perpendiculars

Breadth

9,10 m

Draught

2,60 m

Depth

3,50 m

Speed

Max.: 11,0 knots

Built

2004

Date of completion

01.08.2004

Builder casco

Damen Shipyard Kozle
Kedzierzyn Kozle
Poland

Builder completion

Damen Shipyard Hardinxveld BV
Hardinxveld-Giessendam

The Netherlands

Yard number

1559

Hull material

Steel

Hull type

Single hull

Watertight compartments

4

Continuous decks

1

Main engine

2x Caterpillar type 3508 B TA 4 stroke 8 cylinder 170 x 190 mm diesel engines- total 1.642 kW / 2.230 hp

Built: 2003

Builder: Caterpillar, Inc., Mossville (Illinois) - USA

Propelling system

2x Promarin screw pitch propeller Solid - at 295 rpm in 2x 1.800 mm v.d. Giessen Optima nozzles

Gearboxes

2x Reintjes, type WAF 562L, 5,421:1

Electrical installation

Power voltage: 440 V

Lighting voltage: 230 V

Frequency: 50 Hz

Generators

2x John Deere 4045 TF 258 diesel engines each 140 hp coupled with generators each 97 kVA / 78 kW, 50 Hz, 220/380 V

Bow thruster

100 hp - hydraulically driven

Bollard pull

29,6 t

Tank capacities

Fuel oil: 130,00 m³

Fresh water: 28,00 m³

Lub oil: 1,50 m³

Hydr. oil: 1,00 m³

Deck equipment

1x Deck crane Effer 120.000-2S-L
Anchor winch Ridderinkhof, hydraulic
AH/towing winch, 45 t at 2,5 m/min
Towing hook, SWL - 35 t
Tugger winch, P=8 ts at 4,5 m/min

Anchor, 2x 225 kg Pool (H.H.P.)

Accommodation

Heated and air-conditioned living spaces for 5 persons, consisting of captain’s cabin, C.E. cabin, three single berth cabins, galley and sanitary facilities

Owner

Damen Marine Services B.V.
4200 AA Gorinchem
The Netherlands
