Westerschelde 14 February 2019 |
|
Name |
MAERSK KATE |
|
Previous names |
2010 - 07/2012 Kate Maersk |
|
Type |
Chemical and oil product tanker |
|
IMO-number |
9431276 |
|
Call sign |
9V6044 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
2010 - 07/2012 Denmark, København - Call sign: OYDS2 |
|
GT |
24.463 t |
|
DWT |
Summer: 39.755,8 t |
|
NT |
11.668 t Suez: 21.868,71 t Panama: 24.412 t |
|
Displacement |
45.205 t |
|
Length |
183,20 m overall 176,00 m between perpendiculars |
|
Breadth |
27,40 m moulded |
|
Draught |
Max: 11,79 m |
|
Freeboard |
6.019 mm |
|
Depth |
16,80 m moulded |
|
Speed |
Max: 15,2 knots |
|
Built |
2010 |
|
Delivery date |
17/08/2010 |
|
Builder |
CSSC Offshore And Marine Engineering (Group) Company Limited No. 40 Fang Cun Road, South Guangzhou Guangzhou, 510382 China |
|
Yard number |
06130026 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Dalian/MAN-B&W 6S50MC-C MK7 - 2 stroke 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW at 127 rpm Manufacturer: Dalian Marine |
|
Propellers |
1x Fixed pitch propeller Manufacturer: Yuanhang Propellers Manufacturing Co., Ltd. |
|
Boilers |
1x Fired boiler AQ-18 - 9,0 bar 1x Fired exhaust gas boiler AQ-10/16 - 9,0 bar Manufacturer: Aalborg Industries |
|
Generators |
3x ZJMD/MAN-B&W 6L23/30H - 6 cylinder 225 x 320 mm diesel engines each 960 kW at 900 rpm coupled with generatorsets each 910 ekW |
|
Bow thruster |
1x 883 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity |
39.894,4 m³ excl. slop tank |
|
Slop tank capacity |
3.988,62 m³ |
|
Tank capacities |
Fresh water: 380,10 m³ Diesel oil: 152,80 m³ Lube oil: 147,60 m³ Ballast: 18.996,33 m³ Fuel oil: 1.477,80 m³ |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 10,0 t 1x Monorail stores crane - SWL 3,0 t Manufacturer: TTS Marine 1x Engine room crane - Swl 3,0 t Manufacturer: Danish Crane Building |
|
Crew |
28 |
|
Operator |
Maersk Tankers A/S Esplanaden 50 1098 Copenhagen, K Denmark |
|
Registered owner |
Maersk Tankers Singapore Pte Ltd. |
|
Latest data adjustment |
29 December 2019 |
