Name |
BARTOK |
|
Previous names |
2009 - 08/2018 Besiktas Pera |
|
Type |
Chemical & oil product tanker |
|
IMO-number |
9517458 |
|
Call sign |
5BBV5 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
2009 - 2018 Malta, Valletta - Call sign: 9HA2115 |
|
GT |
2.974 t |
|
DWT |
Summer: 4.121 t |
|
NT |
1.192 t |
|
Length |
98,71 m overall 91,65 m between perpendiculars |
|
Breadth |
14,10 m |
|
Draught |
Max: 5,80 m |
|
Keel to mast end |
30,88 m |
|
Freeboard |
1.411 mm |
|
Depth |
7,20 m |
|
Speed |
Max: 14,0 knots |
|
Built |
2009 |
|
Date of completion |
26/08/2009 |
|
Builder |
Besiktas Shipyard (Besiktas Gemi Insa AS) Yalova Turkey |
|
Yard number |
02 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M20C - 4 stoke single acting 9 cylinder 200 x 300 mm combustion engine Mcr 1.710 kW/ 2.323 hp at 1.000 rpm Build: 17/12/2007 Builder: Caterpillar Motoren GmbH & Co. Kg |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHO 2981HBR08 52,10 m² - 10,0 bar 1x CHR 2982HBR08 58,80 m² - 10,0 bar 1x CHO 2980HBR08 52,10 m² - 10,0 bar |
|
Shaft generator |
1x 290 kVA - 232 kW |
|
Generators |
3x Main diesel generatorsets each 456 kVA - 365 kW - 530 hp |
|
Emergency generator |
1x Diesel generatorset 124 kVA - 99 kW - 149 hp |
|
Bow thruster |
1x 350 kW |
|
Number of cargo tanks |
11 + 2 slop tanks |
|
Cargo tank capacity |
4.178 m³ |
|
Number of pumps |
11x Cargo pumps each 150 m³/h |
|
Tank capacities |
Fuel: 240 m³ |
|
Crew size |
14 |
|
ISM & commercial manager |
GEFO Gesellschaft für Oeltransporte mbH Raboisen 5 20095 Hamburg Germany |
|
Previous operator |
Besiktas Likid Tasimacilik Denizcilik Ticaret A.S., Istanbul - Turkey |
|
Registered owner |
Bartok Tanker GmbH & Co., KG Care of GEFO Gesellschaft fur Oeltransporte mbH Raboisen 5 20095 Hamburg Germany |
|
Latest data adjustment |
28 August 2022 |
